凯斯零件查询(LB324S) - BALER (9/12-) (88.068.008[01]) - SERVICE KIT: REBUILD KIT FOR ELECTRIC BALE LENGTH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
547 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47493853
|
[1] |
FIP KIT
|
ZED
Incl 2 -11
|
| 2. |
47493941
|
[1] |
ARM
|
ZED
|
| 3. |
47461253
|
[1] |
PLATE
|
ZED
|
| 4. |
47487076
|
[1] |
PLATE
|
ZED
|
| 5. |
47493947
|
[1] |
WASHER,9mm ID x 55mm OD x 3mm Thk
|
ZED
|
| 6. |
47483456
|
[1] |
BELLEVILLE WASHER
|
ZED
|
| 7. |
43127
|
[2] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 8. |
86625263
|
[2] |
WASHER,9mm ID x 20mm OD x 1.6mm Thk
|
ZED
|
| 9. |
322358
|
[3] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 10. |
9706690
|
[2] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 11. |
43128
|
[1] |
BOLT,M8 x 1.25 x 30mm, Cl 8.8
|
NH
|
