现代零件查询R290LC-7 TURBOCHARGER PLUMBING(#0112-)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
723 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
TURBO PLUMBING
|
|
| 1. |
3412320
|
[2] |
CLAMP-HOSE
|
|
| 2. |
3907860
|
[2] |
SCREW-HEX HD CAP
|
|
| 3. |
3286499
|
[1] |
HOSE-PLAIN
|
|
| 4. |
3920706
|
[1] |
PLUG-EXPANSION
|
|
| . |
3922789
|
[2] |
CONNECTOR-MALE
|
|
| 5. |
3922794
|
[1] |
SEAL, O-RING
|
|
| 6. |
3922790
|
[1] |
CONNECTOR-MALE
|
|
| 8. |
3678603
|
[1] |
SEAL, O-RING
|
|
| 7. |
3931824
|
[1] |
SEAL/O-RING
|
|
| 9. |
3931973
|
[1] |
TUBE-TURBO OIL DRAIN
|
|
| 10. |
3937216
|
[1] |
HOSE
|
|
| 11. |
3937706
|
[1] |
GASKET-OIL DRAIN
|
|
| 12. |
3916348
|
[1] |
CONNECTION
|
|
| 13. |
554013
|
[1] |
CLAMP-TUBE
|
|
| 14. |
3902662
|
[1] |
NUT-HEX FLANGE
|
|
| N. |
@
|
[1] |
NOT SUPPLIED PARTS
|
|
