纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (01-023[02]) - HYD LINES, UPP (MAIN) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
582 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF03H00004F1 | [1] | HYD LINES.UPP | |
| A7. | YN03H01429D1 | [1] | FLEXIBLE HOSE | KOB |
| A8. | ZS18C12070 | [1] | SCREW,Hex, M12 x 70mm | KOBCAP |
| A9. | YN03H01429D2 | [1] | FLEXIBLE HOSE | KOB |
| A11. | ZS18C12055 | [2] | SCREW,Hex, M12 x 55mm | KOBCAP |
| A13. | YN03H01462P1 | [1] | PLATE | KOB |
| A14. | ZD12A01600 | [2] | O-RING | KOB |
| A15. | ZD12A01800 | [22] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOB |
| A16. | ZD12A02100 | [2] | O-RING | KOB |
| A17. | ZG23F12016 | [4] | HYD CONNECTOR | KOB |
| A17-1. | ZD12P02900 | [1] | O-RING | KOB |
| A18. | HG24F12016G1 | [6] | HYD CONNECTOR | KOB |
| A19. | HG23H12016G1 | [1] | HYD CONNECTOR | KOB Superseded by part number: YW03H01227P1 |
| A21. | HG23H16016G1 | [1] | HYD CONNECTOR | KOB |
| A22. | ZH32X12000 | [1] | 90 ELBOW,Male, 30° Fl, PF 3/4" x PF 3/4", O-Ring | KOBELBOW |
| A22-1. | ZD12P02400 | [1] | O-RING | KOB |
| A23. | ZG33F12012 | [2] | 90 ELBOW,1 3/16"-12 UN x PF 3/4" | KOB |
| A24. | HH25R12012G4 | [1] | HYD CONNECTOR | KOB |
| A25. | ZS18C12075 | [4] | SCREW,Hex, M12 x 75mm | KOBCAP |
| A26. | ZN18C12010 | [1] | NUT | KOB |
| A28. | YN03H01244P1 | [3] | CLAMP | KOB |
| A29. | ZW16H12000 | [16] | WASHER | KOB |
| A30. | ZS18C12025 | [8] | SCREW,Hex, M12 x 25mm | KOBCAP |
| A33. | YN03H01444P1 | [1] | GROMMET | KOB |
| A37. | YN03H01429D8 | [1] | FLEXIBLE HOSE | KOB |
| A43. | YN03H01431P1 | [2] | BUSHING,28mm ID x 56mm OD x 70mm L | KOB |
| A44. | PY01P01043D6 | [2] | CABLE TIE,4.80mm W x 383mm L | KOB |
| . . | YN19H00013F1 | [1] | HYD LINES,SWIVEL | |
| B1. | HH25X08008G2 | [1] | CONNECTION | KOB |
| B1-1. | ZD12P01800 | [1] | O-RING | KOB |
| B3. | YN19H01003P1 | [2] | RIGID TUBE | KOB |
| B4. | YN19H01004P1 | [2] | RIGID TUBE | KOB |
