纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (05-003A[01]) - CAB ASSY (WITHOUT POWER WINDOW) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
939 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 42. | YT54C00001P1 | [2] | WINDSHIELD WASHER | KOBWINDSHIELD WASHER |
| 43. | YT02C01126D4 | [2] | TUBE | KOB Superseded by part number: YT02C01126D1 |
| 77. | YT02C01135P1 | [2] | STOP | KOB Superseded by part number: YN21C03212P1 |
| 99. | ZR36X00600 | [4] | SNAP RING | KOB |
| 112. | ZS32T40012 | [6] | SCREW | KOB |
| 116. | ZM22C08020 | [4] | BOLT | KOB |
| 150. | YT53C00007P1 | [1] | WIPER BLADE | KOB |
| 151. | YT53C00008P1 | [1] | WIPER ARM | KOB |
| 152. | YT76S00001P1 | [1] | MOTOR | KOB |
| 153. | ZS28C06025 | [4] | SCREW,Hex Socket Head, M6 x 25mm | KOB |
| 155. | ZW16K06000 | [4] | WASHER | KOB |
| 164. | ZS18C10040 | [4] | SCREW,Hex, M10 x 40mm | KOB |
| 165. | ZW26K06000 | [4] | LOCK WASHER | KOB |
| 170. | ZN18C10006 | [2] | NUT | KOB |
| 171. | ZN18F10006 | [4] | NUT | KOB |
| 172. | ZN18C10008 | [4] | NUT | KOB |
| 173. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 178. | YT02C01257P1 | [1] | | |
| 179. | YR21C01161P1 | [8] | WASHER,9mm ID x 22mm OD x 2.3mm Thk | KOB |
| 181. | ZM32C12025 | [8] | BOLT | KOB |
| 204. | ZW16H10000 | [8] | WASHER | KOB |
| 265. | YT02C01516P1 | [1] | GUARD | KOB |
| 266. | YT02C01517P1 | [1] | GUARD | KOB Superseded by part number: YT02C01517P2 |
| 267. | YT02C01518P1 | [1] | GUARD | KOB |
