纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (05-013) - HYD. LINE, BOOM (NIBBLER & BREAKER) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
533 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | YF42H01029P1 | [1] | TUBE | KOB |
| 4. | ZD12P03400 | [3] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOB |
| 5. | ZE13X16000 | [6] | FLANGE | KOB |
| 6. | ZS28C12050 | [12] | CAPSCREW,Hex Socket Head, M12 x 50mm | KOB |
| 7. | ZW26K12000 | [12] | LOCK WASHER | KOB |
| 8. | 2432T5924 | [3] | CLAMP | KOB |
| 9. | ZS18C12060 | [6] | SCREW,Hex, M12 x 60mm | KOB |
| 10. | ZW26X12000 | [12] | WASHER | KOB |
| 11. | ZD12P03800 | [3] | O-RING | KOB |
| 12. | ZE13X20001 | [6] | CLAMP | KOB Superseded by part number: ZE13X20000 |
| 13. | ZS28C14050 | [12] | CAPSCREW,Hex Socket Head, M14 x 50mm | KOB |
| 14. | ZW26K14000 | [12] | LOCK WASHER | KOB |
| 15. | LC42H01269P1 | [3] | CLAMP | KOB |
| 16. | ZS18C12065 | [6] | SCREW,Hex, M12 x 65mm | KOB |
