| . . | YR12B00035F2 | [1] | ARM GROUP | |
| A1. | YT12B01022F1 | [1] | LINK | KOBASSY, BUCKET |
| A1-1. | NSS | [1] | NOT SOLD SEPARAT | CONLINK, BUCKET |
| A1-2. | YR12B01079P1 | [1] | BUSHING | KOB |
| A1-3. | LE12B01055P1 | [1] | BUSHING | KOB |
| A2. | YT12B01023F1 | [1] | LINK ASSY. | KOBBUCKET |
| A2-1. | NSS | [1] | NOT SOLD SEPARAT | CONLINK, BUCKET |
| A2-2. | YR12B01079P1 | [1] | BUSHING | KOB |
| A2-3. | LE12B01055P1 | [1] | BUSHING | KOB |
| A5. | YR12B01019P1 | [2] | PIN | KOB |
| A6. | YT12B01018P1 | [1] | PIN | KOB Superseded by part number: YT12B01345P1 |
| A7. | YT12B01019P1 | [1] | PIN | KOB Superseded by part number: YT12B01346P1 |
| A8. | HS18C12100G2 | [2] | SCREW | KOBM12x1.75x100mm |
| A9. | ZN18C12010 | [4] | NUT | KOBM12x1.75mm |
| A10. | 2445R138D19 | [6] | SEAL,50mm ID x 60mm OD x 4mm Thk | KOBDust -- ID 50 x OD 60 x Th 4mm |
| A11. | 2445R220D1 | [2] | SEAL,60mm ID x 75mm OD x 5mm Thk | KOBDust -- ID 60 x OD 75 x Th 5mm |
| A12. | 2445R220D5 | [4] | SEAL,50mm ID x 65mm OD x 5mm Thk | KOBDust -- ID 50 x OD 65 x Th 5mm Superseded by part number: 71436184 |
| A13. | ZG91S02000 | [5] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| A14. | ZG91U02000 | [2] | LUBE NIPPLE | KOB90° x 1/8" PT |
| A15. | 2418T20767 | [1] | SPACER | KOB |
| A16. | YR12B01028P1 | [6] | SHIM,2.0mm Thk | KOB2.0 |
| A17. | B16T0442D25 | [6] | SHIM,80mm OD x 52mm ID x 1.2mm Thk | KOBID 52 x OD 80 x Th 1.2mm |
| A18. | B16T0442D41 | [6] | SHIM,80mm OD x 52mm ID x 0.9mm Thk | KOBID 52 x OD 80 x Th 0.9mm |
| A19. | B16T0442D54 | [6] | SHIM,52mm ID x 80mm OD x 0.5mm Thk | KOBID 52 x OD 80 x Th 0.5mm |
| A20. | YT12B01024P1 | [1] | LINK | KOB Superseded by part number: YT12B01348P1 |
| A21. | YT12B01025P1 | [1] | LINK | KOB |
| . . | YT12B00049F6 | [1] | ARM ASSY, LONG | |
| B2. | YR12B01100P2 | [2] | BUSHING | KOB |
| B3. | LE12B01054P1 | [2] | BUSHING | KOB |
| B7. | LE12B01064P1 | [2] | BUSHING | KOB |
| B6. | NSS | [1] | NOT SOLD SEPARAT | CONARM, LONG |
| B6-2. | YT12B01052P1 | [1] | PLATE | KOBPLATE Superseded by part number: YT12B01052P2 |
| B6-3. | YT12B01053P1 | [1] | PLATE | KOBPLATE Superseded by part number: YT12B01053P2 |
| B6-4. | 2416T24666 | [2] | BRACKET | KOB |
| B6-5. | LE12B01024P1 | [4] | BRACKET | KOB |
| . . | YR12B00025F1 | [1] | ARM INSTAL (KAI. OCEANIA) | |
| . . | YR12B00025F2 | [1] | ARM INSTAL (KCME) | |
| C1. | YT12B01037P1 | [1] | PIN | KOB |
| C2. | YR12B01102P2 | [1] | PIN | KOBPIN |
| C3. | HS18C14120G2 | [1] | SCREW | KOBCAP |
| C4. | ZS18C12025 | [1] | SCREW,Hex, M12 x 25mm | KOBM12x1.75x25mm |
| C5. | ZN18C14011 | [2] | NUT | KOBM14x2.0mm |
| C6. | 2418T21942 | [1] | WASHER | KOBID 13 x OD 45 x Th 4.5mm |
| C7. | ZW26X12000 | [1] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| C8. | YR02B01266D3 | [2] | SHIM,0.5mm Thk | KOB0.5 |
| C9. | YR02B01266D1 | [2] | SHIM,0.9mm Thk | KOB0.9 |
| C10. | YR02B01265P1 | [2] | SHIM,2.0mm Thk | KOB2.0 |
| C11. | 2418T4037D7 | [1] | SHIM,67mm ID x 110mm OD x 0.5mm Thk | KOBID 67x OD 110 x Th 0.5mm |
| G12. | 2418T4037D3 | [1] | SHIM,67mm ID x 110mm OD x 0.9mm Thk | KOBID 67x OD 110 x Th 0.9mm |
| C13. | 2418T4037D2 | [1] | SHIM,67mm ID x 110mm OD x 1.2mm thk | KOBID 67x OD 110 x Th 1.2mm |
| C14. | YR12B01103P1 | [2] | SHIM | KOB3.0 |
| C15. | YT12B01087P1 | [1] | PIN | KOB |
