神钢零件查询(ED150) - BLADE RUNNER EXCAVATOR/DOZER ASN YH02-01384 (4/02-12/03) (04-016) - MOTOR ASSY (PROPELLING) (PN YY15V00007F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
709 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY15V00007F1 | [1] | HYDRAULIC MOTOR | KOBMOTOR ASSY (PROPELLING) Superseded by part number: YY15V00007F2 |
| 1. | YY15V00007S001 | [1] | CASE | KOBCASE |
| 2. | YY15V00007S002 | [1] | COVER | KOBCOVER Superseded by part number: YN15V00017S002 |
| 3. | YY15V00007S003 | [1] | CYLINDER BLOCK | KOBBLOCK, CYLINDER Superseded by part number: YN15V00017S003 |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONRETAINER, SHOE |
| 5. | YY15V00007S005 | [3] | PLATE | KOBPLATE, FRICTION |
| 6. | YY15V00007S006 | [1] | PISTON | KOBPISTON, BRAKE Superseded by part number: YN15V00009S006 |
| 7. | YY15V00007S007 | [4] | PLATE | KOBPLATE, SEPARATOR |
| 8. | YN15V00017S008 | [1] | PLATE | KOBVALVE |
| 9. | YN15V00017S009 | [1] | SHAFT | KOB |
| 10. | YN15V00017S010 | [1] | COUPLING | KOB |
| 11. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE, SHOE |
| 12. | NSS | [1] | NOT SOLD SEPARAT | CONJOINT, BALL |
| 13. | YY15V00007S013 | [1] | SPRING SEAT | KOBSEAT, SPRING |
| 14. | NSS | [9] | NOT SOLD SEPARAT | CONPISTON ASSY |
| 15. | YY15V00007S015 | [1] | RING | KOBRING |
| 16. | YY15V00007S016 | [1] | RING | KOBRING |
| 17. | YY15V00007S017 | [3] | CHECK VALVE | KOBVALVE, CHECK |
| 18. | ZR26X03200 | [1] | SNAP RING | KOBRetaining -- ID 32 x OD 34.4 x Th 1.2mm |
| 19. | YY15V00007S019 | [1] | RING | KOBRING, RETAINING |
| 20. | NSS | [1] | NOT SOLD SEPARAT | CONPISTON |
| 21. | NSS | [1] | NOT SOLD SEPARAT | CONBALL |
| 22. | NSS | [2] | NOT SOLD SEPARAT | CONPIVOT |
| 23. | YY15V00007S023 | [1] | SEAL | KOBSEAL, PISTON Superseded by part number: YN15V00003S024 |
| 24. | PR30V00010S014 | [2] | ORIFICE | KOB |
| 25. | YY15V00007S025 | [1] | OIL SEAL | KOBOIL SEAL Superseded by part number: YN15V00009S027 |
| 26. | YN15V00017S026 | [3] | SPRING | KOB |
| 27. | YY15V00007S027 | [9] | SPRING | KOBSPRING |
| 28. | YN15V00017S028 | [12] | SPRING | KOB |
| 29. | YN15V00017S029 | [1] | BEARING | KOB Superseded by part number: 86557434 |
| 30. | YN15V00017S030 | [1] | BEARING | KOB |
| 31. | ZS23C16045 | [8] | CAP,Hex Socket Head, M16 x 45mm | KOBScrew -- M16x2.0x45mm |
| 32. | YN15V00017S032 | [1] | SHIM | KOB |
| 33. | YN15V00017S033 | [1] | PIN | KOB |
| 34. | 2436U279S3 | [1] | PLUG | KOB |
| 35. | 2436U1427S25 | [10] | PLUG | KOB |
| 36. | 2436U1749S17 | [1] | PLUG | KOB |
| 37. | YY15V00007S037 | [3] | PLUG | KOBPLUG Superseded by part number: YN15V00017S038 |
| 38. | 2436U1317S13 | [2] | PLUG | KOB |
| 39. | ZD12P00800 | [5] | O-RING,1.9mm Thk x 7.8mm ID, 90 Duro | KOBID 7.8mm x OD 9.7mm |
| 40. | ZD12P01100 | [4] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 41. | ZD12P01400 | [2] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 42. | YY15V00007S042 | [1] | O-RING | KOBO-RING |
| 43. | YY22V00009F1 | [2] | VALVE | KOBVALVE ASSY, OVERLOAD RELIEF, SEE FIGURE 04-017 Superseded by part number: YN22V00013F1 |
| 44. | YN15V00017S045 | [1] | SPOOL | KOB |
| 45. | YN15V00017S046 | [1] | PLUG | KOB |
| 46. | 2436R874S5 | [1] | SPRING SEAT | KOB |
| 47. | 2436R874S6 | [1] | PIN | KOB |
| 48. | 2436R874S7 | [1] | SPRING | KOB |
| 49. | 2436R874S3 | [1] | FLEXIBLE JOINT | KOBCONNECTOR |
| 50. | YN15V00017S051 | [1] | SPOOL | KOBASSY |
| 51. | YN15V00017S052 | [2] | COVER | KOB |
| 52. | YN15V00017S053 | [2] | SPRING | KOB |
| 53. | YN15V00017S054 | [2] | SEAT | KOBSPRING |
| 54. | 2436U1384S8 | [2] | VALVE | KOB |
| 55. | YY15V00007S055 | [2] | SPRING | KOBSPRING |
| 56. | 2436U1139S10 | [2] | PLUG | KOB |
| 57. | YN15V00017S058 | [2] | O-RING | KOB |
| 58. | ZD12P00900 | [2] | O-RING | KOBID 08.80 ± 0.17 x OD 12mm |
| 59. | ZS23C12035 | [8] | SCREW,Hex Socket Head, M12 x 35mm | KOBM12x1.75x35mm |
