纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (01-030[01]) - CONTROL LINES, REMOTE, P/N YF64H00011F1 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
1000 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF64H00011F1 | [1] | CONTROL LINES, VALVE | |
| 1. | YB35V00002F2 | [1] | VALVE | KOBASSY, SOLENOID |
| 3. | 2432R325 | [2] | CLIP | KOB |
| 4. | ZS18C12035 | [2] | SCREW,Hex, M12 x 35mm | KOBCAP |
| 5. | ZS18C10075 | [2] | SCREW,Hex, M10 x 75mm | KOBCAP |
| 6. | ZS18C10020 | [3] | SCREW,Hex, M10 x 20mm | KOBCap |
| 8. | ZS18C12025 | [1] | SCREW,Hex, M12 x 25mm | KOBCAP |
| 9. | ZW16H12000 | [3] | WASHER | KOB |
| 11. | ZW16H10000 | [5] | WASHER | KOB |
| 12. | 2444R1119D105 | [1] | HOSE | KOB |
| 13. | ZX23M06050 | [1] | FLEXIBLE HOSE | KOB |
| 14. | 2420R349D130 | [1] | FLEXIBLE HOSE | KOB |
| 15. | 2420R349D100 | [1] | HOSE | KOB Superseded by part number: HX21E04100DX |
| 16. | 2420R537D250 | [1] | HOSE ASSY.,9.60mm ID x 2500mm L | KOB |
| 18. | 2420R349D140 | [1] | HOSE,6.35mm ID x 1400mm L | KOB |
| 19. | 2420R349D120 | [1] | HOSE,6.35mm ID x 1200mm L | KOB |
| 20. | 2420R349D038 | [1] | HOSE | KOBHOS Superseded by part number: 2420R349D040 |
| 21. | 2420R349D034 | [1] | HOSE | KOBHOSE Superseded by part number: 2420R349D035 |
| 23. | 2420R349D160 | [1] | HOSE,6.35mm ID x 1600mm L | KOB |
| 25. | YN64H01072P1 | [1] | U-BRACKET | KOB |
| 28. | ZH32X04000 | [9] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOBELBOW |
| 29. | ZH32X06000 | [2] | 90 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 30. | HH35X06006G3 | [1] | ELBOW | KOB |
| 32. | 2444Z3711 | [2] | HYD CONNECTOR | KOB |
| 33. | 2444Z2525 | [2] | HYD CONNECTOR | KOB |
| 34. | 2420Z699 | [1] | GROMMET | KOB |
| 35. | ZC46X22011 | [1] | CLIP | KOB |
| 36. | YN64H01175P1 | [1] | BUSHING | KOB |
| 37. | PU13E01002D9 | [2] | TUBE | KOB |
| 38. | PU13E01002DU | [1] | TUBE | KOB |
| 39. | PY01P01043D3 | [3] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
