斗山零件查询CONTROL STAND-LH SOLAR 290LC-V Doosan parts catalog online
广数供应链运营团队, 15 02月, 2025，浏览：
748 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| -. |
2197-1825F2B
|
[-] |
CONTROL STAND ASS'Y
|
|
| -. |
2197-1825F2C
|
[-] |
CONTROL STAND ASS'Y
|
|
| -. |
2197-1825F2E
|
[-] |
CONTROL STAND ASS'Y
|
|
| -. |
2197-1825F2H
|
[-] |
CONTROL STAND ASS'Y
|
|
| -. |
2197-1825F2K
|
[-] |
CONTROL STAND ASS'Y
|
|
| 1. |
2160-1004D9
|
[1] |
GROMMET
|
|
| 11. |
2891-1361
|
[1] |
SWITCH PLATE
|
|
| 12. |
2123-2240
|
[1] |
PIN
|
|
| 13. |
2621-3775
|
[1] |
HOLE COVER;STAND
|
|
| 19. |
2158-1021
|
[1] |
PROTECTOR
|
|
| 20. |
2440-9258
|
[1] |
SPRING;GAS
|
|
| 25. |
2191-3314
|
[1] |
PLATE
|
|
| 25. |
2627-1909
|
[1] |
PLATE
|
|
| 25. |
2627-1909A
|
[1] |
PLATE
|
2627-1909B
|
| 25. |
2627-1909B
|
[1] |
PLATE
|
|
| 26. |
2549-1134
|
[1] |
SWITCH;MICRO
|
|
| 26. |
2549-9139
|
[1] |
SWITCH;MICRO
|
|
| 27. |
S8450066
|
[2] |
CLAMP;HOSE
|
|
| 29. |
S0151313
|
[2] |
BOLT M4X0.7X25
|
2120-2166D21
|
| 29. |
2120-2166D21
|
[2] |
BOLT M4X0.7X25
|
|
| 30. |
S6541900
|
[1] |
RING;RETAINER
|
|
| 31. |
S6540500
|
[1] |
RING;RETAINING
|
|
| 32. |
2120-2166D5
|
[6] |
BOLT
|
|
| 33. |
S5102503
|
[1] |
. WASHER
|
|
| 34. |
S5020513
|
[3] |
WASHER
|
|
| 37. |
2114-1898D4
|
[6] |
WASHER
|
|
| 37. |
2114-1898D4
|
[12] |
WASHER
|
|
| 40. |
S5000113
|
[2] |
WASHER
|
2114-1898D13
|
| 40. |
2114-1898D13
|
[2] |
WASHER
|
|
| 41. |
S2203061
|
[7] |
BOLT;SOCKET M5X0.8X14
|
|
| 41. |
S2203061
|
[8] |
BOLT;SOCKET M5X0.8X14
|
|
| 42. |
2114-4129
|
[1] |
WASHER
|
|
| 43. |
2114-1059D31
|
[3] |
SHIM
|
|
| 44. |
2530-1438
|
[1] |
HARNESS;MICRO SWITCH
|
2530-1782
|
| 44. |
2530-1782
|
[1] |
HARNESS;MICRO SWITCH
|
|
| 48. |
2114-1898D2
|
[6] |
WASHER
|
|
| 49. |
2197-1823
|
[1] |
BRACKET
|
|
| 49. |
2197-1823A
|
[1] |
BRACKET
|
2197-1823B
|
| 49. |
2197-1823B
|
[1] |
BRACKET
|
2197-1823C
|
| 49. |
2197-1823C
|
[1] |
BRACKET
|
|
| 49-12. |
2110-1184D37
|
[2] |
. BUSH;DU
|
|
| 50. |
2120-2166D8
|
[4] |
BOLT
|
|
| 51. |
S4012103
|
[2] |
NUT M4X0.7
|
|
| 6. |
2133-2027
|
[1] |
SAFETY LEVER ASS'Y
|
2133-2027A
|
| 6. |
2133-2027A
|
[1] |
SAFETY LEVER ASS'Y
|
2133-2027B
|
| 6. |
2133-2027B
|
[1] |
SAFETY LEVER ASS'Y
|
|
| 6-1. |
2116-1524
|
[1] |
PLATE
|
2116-1524A
|
| 6-1. |
2116-1524A
|
[1] |
PLATE
|
|
| 6-10. |
S5000113
|
[4] |
WASHER
|
|
| 6-10. |
S5000113
|
[6] |
WASHER
|
|
| 6-11. |
2110-1184D29
|
[1] |
. BUSH;DU
|
|
| 6-12. |
S3452583
|
[1] |
. SCREW M4X0.7X12
|
|
| 6-13. |
2132-1132
|
[1] |
GRIP
|
2132-1132A
|
| 6-13. |
2132-1132A
|
[1] |
. GRIP
|
|
| 6-14. |
S3458713
|
[1] |
SCREW M5X0.8X12
|
|
| 6-14. |
2120-2166D31
|
[1] |
BOLT M5X0.8X12
|
|
| 6-15. |
S5102203
|
[1] |
WASHER
|
|
| 6-15. |
2114-2031D2
|
[1] |
WASHER;SPRING M5
|
|
| 6-16. |
S5000213
|
[1] |
. WASHER
|
|
| 6-16. |
2114-1898D5
|
[1] |
WASHER
|
|
| 6-17. |
116-00003
|
[1] |
PIN
|
116-00003A
|
| 6-17. |
116-00003A
|
[1] |
PIN
|
|
| 6-18. |
2121-1311D2
|
[1] |
NUT
|
|
| 6-19. |
2114-1898D14
|
[1] |
WASHER
|
|
| 6-2. |
2133-2003
|
[1] |
LEVER
|
2133-2003A
|
| 6-2. |
2133-2003A
|
[1] |
LEVER
|
|
| 6-20. |
2114-2031D4
|
[1] |
WASHER
|
|
| 6-3. |
2116-1485
|
[1] |
PLATE
|
|
| 6-4. |
2123-2146A
|
[1] |
PIN
|
|
| 6-5. |
2123-2279
|
[1] |
PIN
|
2123-2279A
|
| 6-5. |
2123-2279A
|
[1] |
PIN
|
|
| 6-6. |
2114-1059D37
|
[2] |
. SHIM
|
|
| 6-7. |
2129-1432
|
[1] |
. SPRING
|
|
| 6-8. |
S3450583
|
[4] |
SCREW
|
|
| 6-8. |
S3450583
|
[6] |
SCREW
|
|
| 6-9. |
S5102103
|
[4] |
WASHER
|
|
| 7. |
2197-1634A
|
[1] |
BRACKET;LOWER ASS'Y
|
|
| 7. |
2197-1634B
|
[1] |
BRACKET;LOWER ASS'Y
|
|
| 7. |
2197-1634C
|
[1] |
BRACKET;LOWER ASS'Y
|
|
| 7. |
2197-1634E
|
[1] |
BRACKET;LOWER ASS'Y
|
|
| 7-1. |
NA00816
|
[1] |
PLATE
|
|
| 7-10. |
2129-1433A
|
[1] |
SPRING
|
|
| 7-6. |
2133-1989A
|
[1] |
LEVER
|
|
| 7-6. |
2133-1989B
|
[1] |
LEVER
|
|
| 7-7. |
2110-1184D29
|
[2] |
. BUSH;DU
|
|
| 7-8. |
2114-1059D200
|
[1] |
SHIM
|
|
| 7-9. |
S6541200
|
[1] |
. RING;RETAINER
|
|
| 8. |
2125-1093
|
[1] |
STAND CASE-A LH
|
|
| 8. |
2125-1093A
|
[1] |
STAND CASE-A LH
|
|
| 9. |
2125-1094
|
[1] |
STAND CASE-B LH
|
2125-1094A
|
| 9. |
2125-1094A
|
[1] |
STAND CASE-B LH
|
2125-1094B
|
| 9. |
2125-1094B
|
[1] |
STAND CASE-B LH
|
|
