| . . | YF06H00002F2 | [1] | CONTROL LINES, PUMP | |
| A1. | 2420R349D040 | [1] | HOSE,6.35mm ID x 400mm L | KOB |
| A2. | 2420R349D255 | [1] | HOSE | KOB Superseded by part number: HX21E04255DX |
| A3. | 2420R537D230 | [1] | FLEXIBLE HOSE,9.60mm ID x 2300mm L | KOB |
| A6. | PU13E01002D9 | [1] | TUBE | KOB |
| A9. | ZH42X06000 | [1] | 45 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOB |
| A10. | HH35X04004G3 | [1] | 90 ELBOW | KOB |
| A11. | ZH32X04000 | [1] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOBELBOW |
| A12. | ZH32X06000 | [2] | 90 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| A13. | HH55Q06006G1 | [1] | TEE | KOB |
| A14. | HH55Q04004G1 | [1] | TEE,1/4" ORB x 1/4" JIC x 1/4" JIC | KOB |
| A15. | YN50V00016F1 | [1] | FILTER | KOBASSY, INLINE |
| A16. | ZS18C06060 | [2] | SCREW,Hex, M6 x 60mm | KOBCAP |
| A17. | ZW16H06000 | [2] | WASHER | KOB |
| A18. | ZD12P02400 | [1] | O-RING | KOB |
| A19. | ZC16X03300 | [2] | FASTENER | KOBCLIP |
| A20. | PY01P01043D6 | [2] | CABLE TIE,4.80mm W x 383mm L | KOB |
| A21. | HH25X04004G2 | [1] | HYD CONNECTOR | KOB |
| A23. | ZS18C12020 | [2] | SCREW,Hex, M12 x 20mm | KOB |
| A24. | ZW16H12000 | [2] | WASHER | KOB |
| A25. | LQ60C01033D4 | [1] | RIGID TUBE | KOB |
| A26. | ZH22X06000 | [1] | HYD CONNECTOR | KOB |
| A27. | ZH32X04006 | [1] | 90 ELBOW,Male, 30° Fl, PF 1/4" x PF 3/8", O-Ring | KOB |
| . . | YF62H00001F1 | [1] | CONTROL LINES, PROPEL | |
| B2. | 2420R537D320 | [2] | HOSE ASSY.,9.60mm ID x 3200mm L | KOB |
| B3. | 2444R1119D038 | [1] | FLEXIBLE HOSE | KOB |
| B4. | 2420R349D030 | [1] | HOSE,300.00 mm | KOB |
| B5. | YX30V00004F1 | [1] | VALVE | KOBASSY, PILOT, Serial Range: YU04-00837-YU04-00985 Superseded by part number: YX30V00004F2 |
| B5. | YX30V00004F2 | [1] | PILOT VALVE | KOBASSY, Start Serial: YU04-00986 |
| B9. | ZW16K10000 | [4] | WASHER | KOB |
| B10. | ZS28C10030 | [4] | SCREW,Hex Socket Head, M10 x 30mm | KOBCAP |
| B11. | LC52S00011P1 | [2] | SENSOR | KOBPRESS (L P.) Superseded by part number: LC52S00019P1 |
| B11-1. | ZD12P01100 | [1] | O-RING | KOB |
| . . | YF64H00010F1 | [1] | CONTROL LINES, BLOCK | |
| C1. | 2416N6141 | [1] | BLOCK | KOB |
| C2. | ZS18C08040 | [2] | SCREW,Hex, M8 x 40mm | KOBM08x1.25x40mm |
| C3. | ZW16H08000 | [2] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| C6. | ZH42X04000 | [1] | 45 ELBOW,Male, 30° Fl, PF 1/4" x PF 1/4", O-Ring | KOBELBOW, 45 |
| C9. | 2444Z2525 | [1] | HYD CONNECTOR | KOB |
| C17. | ZE72X04000 | [1] | PLUG | KOB |
| C18. | ZE72X06000 | [1] | PLUG | KOB |
