纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (01-049[02]) - CONTROLLER GROUP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
712 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| .. | YF22E00020F1 | [1] | CONTROLLER ASSY, Serial Range: YU04-00837-YU04-00871 | |
| .. | YF22E00020F3 | [1] | CONTROLLER ASSY, Serial Range: YU04-00872-YU04-00897 | |
| .. | YF22E00020F5 | [1] | CONTROLLER ASSY, Start Serial: YU04-00898 | |
| A2. | YY22E01006P1 | [2] | BRACKET | KOB |
| A4. | YF14E00007F1 | [1] | HARNESS ASSY,CAB | |
| A4-1. | ZM61C06020 | [4] | BOLT | KOBSEMS |
| A4-2. | ZM61C06016 | [3] | BOLT | KOBSEMS |
| A4-3Ba. | YN73E00001S001 | [1] | BASE | KOB |
| A4-3Bb. | YN73E00001S002 | [1] | COVER | KOB |
| A4-3Bc. | 2479R655S8 | [11] | FUSE,10 Amp | KOB(10A) Superseded by part number: 87522597 |
| A4-3Bd. | 2479R655S9 | [9] | FUSE | KOB(20A) |
| A4-3Bf. | YF73E01002P1 | [1] | LABEL | |
| A4-4. | 2432R233D1 | [1] | CLIP | KOB |
| A4-6. | YN03E01001D5 | [7] | CLIP | KOB |
| A4-7. | 2427Z1594D003 | [1] | SOFT TRIM | KOB |
| A5. | LC22E01001D1 | [1] | RESISTOR,16ohm | KOB |
| A6. | YT50E00001F1 | [1] | SWITCH | KOBASSY Superseded by part number: YN50S00047P1 |
| A7. | YN50S01003P1 | [1] | SWITCH | KOBASSY |
| A8. | EN24S00008P1 | [7] | RELAY | KOB |
| A9. | 2427Z1594D006 | [1] | TRIM PANEL | KOB |
| A10. | 2427Z1594D008 | [2] | PROTECTION STRIP | KOBTRIM Superseded by part number: S16539-17000 |
| A11. | 2427Z1594D028 | [2] | TRIM PANEL | KOB |
| A12. | YT22E01006P1 | [1] | LABEL | KOB |
| A13. | YV22E01002P1 | [1] | LABEL | KOB |
| A14. | ZM41C04012 | [1] | BOLT | KOBSEMS |
| A15. | ZM61C06012 | [11] | BOLT | KOBSEMS |
| A16. | ZM61C06030 | [3] | BOLT | KOBSEMS |
| A18. | ZW16X06000 | [7] | WASHER | KOB Superseded by part number: 86588450 |
| A21. | ZM61C06025 | [1] | BOLT | KOBSEMS |
| A23. | YN25S00001P1 | [1] | TIMER | KOB |
| A24. | LC24S00001P1 | [1] | RELAY | KOB |
| A25. | YF22E00001F3 | [1] | CONTROLLER ASSY, (FOR F3 ONLY) | |
| A20. | ME077148 | [1] | STARTER SAFETY RELAY, MITSUBISHI E/G PARTS | |
| B1. | ZM22C10025 | [4] | BOLT | KOBSEMS |
| B2. | YT22E01026P1 | [1] | INDICATOR | KOBINSULATION |
| B3. | 2432R233D2 | [1] | CLIP | KOB37x12x40mm |
