纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (01-053) - CONDITIONER ASSY, AIR, P/N YF20M00003F1 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
884 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF20M00003F1 | [1] | CONDITIONER ASSY, AIR | |
| 1. | YT20M00009F3 | [1] | CONDITIONER ASSY, AIR, SEE FIG 01-054 | |
| 3. | YX91V00002F2 | [1] | COMPRESSOR | KOBASSY, AIR, SEE FIG 01-056 |
| 4. | YT20M01104F1 | [1] | PANEL | KOBASSY, SEE FIG 01-057 |
| 5. | YT95V00001F1 | [1] | FILTER ASSY | KOBAIR, SEE FIG 01-057 |
| 6. | YT20M01060P2 | [1] | CONDENSER | KOB |
