纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (01-063[02]) - HARNESS ASSY, UPP (FLOOR PLATE) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
277 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF13E00004F2 | [1] | HARNESS ASSY, UPP | |
| 2. | LE13E01005P1 | [1] | CABLE,100mm L | KOB |
| 3. | ZS18C08016 | [1] | SCREW,Hex, M8 x 16mm | KOBCAP |
| 4. | ZW26X08000 | [1] | LOCK WASHER | KOBLock Superseded by part number: 83990583 |
| 5. | ZW16X08000 | [1] | WASHER | KOB |
| 6. | PY01P01043D3 | [1] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 8. | PY01P01043D5 | [2] | CABLE TIE,301mm L | KOB |
