纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (01-064[02]) - HARNESS ASSY, ENGINE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
669 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF16E00001F1 | [1] | HARNESS ASSY, ENGINE, Serial Range: YU04-00837-YU04-01090 | |
| . . | YF16E00001F2 | [1] | HARNESS ASSY,ENGINE, Start Serial: YU04-01091 | |
| 2. | YN16E01018P1 | [1] | BRACKET | KOB |
| 3. | YN16E01022P2 | [1] | BRACKET | KOB |
| 4. | 2432R233D1 | [1] | CLIP | KOB |
| 5. | 2418T26637D1 | [2] | SPACER | KOB |
| 6. | 2432R233D3 | [6] | CLIP | KOB |
| 7. | ZN18C10008 | [1] | NUT | KOBM10x1.50mm |
| 8. | ZN18C06005 | [2] | NUT | KOB |
| 9. | ZW26X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 11. | ZM66C06016 | [2] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| 13. | ZM22C10040 | [2] | BOLT | KOBSEMS |
| 14. | ZW26X06000 | [3] | LOCK WASHER | KOB |
| 15. | ZW16X10000 | [3] | WASHER | KOB |
| 16. | ZS18C05010 | [1] | SCREW,Hex, M5 x 10mm | KOBCAP |
| 17. | PY01P01043D3 | [2] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 18. | ZW26X05000 | [1] | LOCK WASHER | KOBLOCK |
| 19. | ZS18C10020 | [1] | SCREW,Hex, M10 x 20mm | KOBCap |
| 20. | ZS18C08016 | [2] | SCREW,Hex, M8 x 16mm | KOBCAP |
| 21. | ZW16X08000 | [2] | WASHER | KOB |
| 22. | ZS18C06010 | [1] | SCREW,Hex, M6 x 10mm | KOBCAP |
| 24. | ZW16X06000 | [1] | WASHER | KOB, Start Serial: YU04-01091 Superseded by part number: 86588450 |
| 26. | ZW16X05000 | [1] | WASHER | KOB, Start Serial: YU04-01091 |
