纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (02-015-00[01]) - WATER CIRCUIT - THERMOSTAT New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
692 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 426196A1 | [2] | THERMOSTAT | ISU Superseded by part number: 47848257 |
| 2. | 426197A1 | [1] | HOUSING | ISU |
| 12. | 419915A1 | [5] | BOLT | ISUM10 x 25 |
| 20. | 426198A1 | [2] | O-RING | ISU |
| 30. | 426092A1 | [1] | PUMP, WATER | ISU |
| 59. | 426200A1 | [2] | GASKET | ISU16,2 ID |
| 60. | 288817A1 | [1] | SENSOR | ISU |
| 66. | 438021A1 | [1] | GASKET | ISU105,6 ID |
| 67. | 426204A1 | [1] | GASKET | ISU Superseded by part number: 72110353 |
| 112. | 355157A1 | [2] | PLUG | ISU Superseded by part number: 84387716 |
| 112. | 426205A1 | [1] | PLUG | ISUM16, PT 3/8 Superseded by part number: 71455253 |
