纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (02-019-00[01]) - EXHAUST PIPE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
989 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 426064A1 | [6] | MANIFOLD GASKET | ISU |
| 5. | 426065A1 | [1] | MANIFOLD | ISU |
| 6. | 426066A1 | [1] | MANIFOLD | ISU |
| 18. | 426067A1 | [18] | FLANGE NUT | ISUM10 Superseded by part number: 87596349 |
| 32. | 426068A1 | [18] | WASHER | ISU2,2 mm Superseded by part number: 71455326 |
| 33. | 426069A1 | [18] | WASHER | ISU5,5 mm Superseded by part number: 71455325 |
| 34. | 426070A1 | [18] | SPACER | ISU Superseded by part number: 84155457 |
| 47. | 426071A1 | [1] | MANIFOLD | ISU |
| 49. | 87328791 | [2] | STUD | ISU |
| 49. | 426073A1 | [2] | STUD | ISU Superseded by part number: 72110119 |
| 58. | 362157A1 | [6] | STUD | CASM8 x 20 Superseded by part number: 87603352 |
| 155. | 426074A1 | [2] | COMPOSITE RING | ISU |
| 156. | 426075A1 | [4] | COMPOSITE RING | ISU Superseded by part number: 71456083 |
