神钢零件查询(ED150) - BLADE RUNNER EXCAVATOR/DOZER BTW YL04-00501 - YL04-00554 (4/03-10/03) (01-016) - VALVE INSTAL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
884 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 0. | YY30V00044F1 | [1] | VALVE | KOBASSY, CONTROL |
| . . | YX64H00002F1 | [1] | VALVE | KOBINSTAL |
| 1. | YX64H01034P1 | [1] | BRACKET | KOB |
| 2. | ZS18C12030 | [6] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 3. | ZS18C12060 | [2] | SCREW,Hex, M12 x 60mm | KOBM12x1.75x60mm |
| 4. | ZW16H12000 | [11] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 5. | ZN18C12010 | [3] | NUT | KOBM12x1.75mm |
| 6. | YX64H01010P1 | [2] | PLATE | KOB |
| 7. | ZS18C12045 | [2] | SCREW,Hex, M12 x 45mm | KOBM12x1.75x45mm |
| 8. | ZS18C12070 | [1] | SCREW,Hex, M12 x 70mm | KOBM12x1.75x70mm |
