纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (02-035-00[01]) - OIL COOLER - OIL FILTER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
968 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 21. | 288565A1 | [2] | GASKET | ISU Superseded by part number: 72110175 |
| 47. | 426458A1 | [1] | PACKING RING | ISU Superseded by part number: 72110441 |
| 76. | 426461A1 | [4] | BOLT | ISUM10 x 50 |
| 77. | 426102A1 | [4] | BOLT | ISUM10 x 90 Superseded by part number: 87597043 |
| 100. | 289998A1 | [2] | PLUG | ISU |
| 102. | 426462A1 | [1] | COOLER, OIL | ISU |
| 103. | 426208A1 | [17] | BOLT | ISUM10 x 30 |
| 104. | 426463A1 | [8] | BOLT | ISUM10 x 65 |
| 105. | 426465A1 | [1] | BOLT | ISUM10 x 110 |
| 110. | 426466A1 | [1] | BODY | ISU |
| 111. | 426467A1 | [1] | BODY | ISU |
| 114. | 426468A1 | [1] | PLATE | ISU |
| 175. | 426472A1 | [1] | GASKET,18.2mm ID x 24.4mm OD | ISU18,2 ID x 24,4 OD |
| 196. | 426473A1 | [1] | THERMOSTAT | ISU Superseded by part number: 72110450 |
| 197. | 426475A1 | [1] | GASKET | ISU Superseded by part number: 72110451 |
| 198. | 426476A1 | [1] | ELBOW | ISU |
| 199. | 426477A1 | [2] | BOLT | ISUM10 x 35 |
| 202. | 288856A1 | [1] | HOSE | SUM |
| 321. | 426413A1 | [1] | GASKET | ISU18,8 ID |
| 321. | 426494A1 | [3] | GASKET,312mm ID | ISU31,2 ID |
| 338. | 426495A1 | [1] | FILTER, ENGINE OIL | ISU |
| 380. | 426496A1 | [1] | FITTING | ISU |
| 444. | 426499A1 | [2] | GASKET | ISU Superseded by part number: 72110472 |
| 462. | 426500A1 | [1] | MOUNTING CLIP | ISU14 mm |
| 471. | 446627A1 | [1] | GASKET | ISU |
| 495. | 426503A1 | [1] | FILTER ASSY | ISU |
| 496. | 426504A1 | [1] | PIPE | ISU |
| 497. | 288993A1 | [1] | FLANGE BOLT | ISU |
| 498. | 426505A1 | [1] | COLLAR | ISU |
| 499. | 426506A1 | [1] | RING | ISU |
| 500. | 426507A1 | [2] | WASHER | ISU10 ID x 2 mm |
| 501. | 289783A1 | [2] | LOCK WASHER | ISU Superseded by part number: 87592300 |
| 502. | 426508A1 | [1] | COVER | ISU |
| 503. | 426509A1 | [4] | BOLT | ISU |
| 504. | 426510A1 | [4] | WASHER | ISU |
| 506. | 426512A1 | [10] | SCREW | ISUM6 x 10 |
| 507. | 426513A1 | [10] | WASHER | ISU |
