神钢零件查询(ED150) - BLADE RUNNER EXCAVATOR/DOZER BTW YL04-00501 - YL04-00554 (4/03-10/03) (01-048) - GAUGE, CLUSTER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
158 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY59S00003F1 | [1] | GAUGE | KOBCLUSTER used for NA |
| 1. | YT59S00001S001 | [1] | COVER | KOB |
| 2. | YT59S00001S002 | [1] | COVER | KOB |
| 3. | YR59S00005S003 | [1] | COVER | KOB Superseded by part number: YY59S00003F1 |
| 4. | YV59S00004S004 | [1] | COVER | KOB |
| 5. | LC59S00001S004 | [1] | SWITCH | KOB |
| 6. | YT59S00001S005 | [1] | METER | KOB |
| 7. | YT59S00001S006 | [1] | GAUGE | KOB |
| 8. | YV59S00001S008 | [1] | BOARD | KOB Superseded by part number: 72958275 |
| 9. | YT59S00001S007 | [1] | BOARD | KOB |
| 10. | YV59S00001S010 | [1] | BOARD | KOB Superseded by part number: YV59S00001F1 |
| 11. | YT59S00001S009 | [1] | BRACKET | KOB |
| 13. | LC59S00001S012 | [1] | GASKET | KOB |
| 14. | LC59S00001S013 | [3] | BULB | KOB |
| 15. | LC59S00001S014 | [1] | SOCKET ASSY | KOBSOCKET, ASSY |
| 16. | YT59S00001S015 | [4] | NUT | KOB |
| 17. | YT59S00001S016 | [4] | SCREW,Phillips Drive, Pan HD, M4 x 10mm | KOBTAPPING Superseded by part number: ZS31C04010 |
| 18. | LC59S00001S015 | [4] | SCREW | KOB |
| 19. | LC59S00001S016 | [10] | SCREW | KOBTAPPING |
| 20. | LC59S00001S017 | [6] | SCREW | KOB |
