神钢零件查询(ED150) - BLADE RUNNER EXCAVATOR/DOZER BTW YL04-00501 - YL04-00554 (4/03-10/03) (01-058[01]) - CONDITIONER ASSEMBLY, AIR P/N YT20M00004F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
818 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT20M00004F1 | [1] | CONDITIONING UNIT | KOBCONDITIONER ASSY.A1, Serial Range: YH02-01301-YH02-01552 Superseded by part number: YT20M00004F2 |
| . . | YT20M00004F2 | [1] | AIR CONDITIONER,Assembly | KOBCONDITIONER ASSY,A1, Start Serial: YH02-01553 |
| 1. | YT20M00004S001 | [3] | ACTUATOR | KOB |
| 2. | YT20M00004S002 | [1] | VALVE | KOBExpansion |
| 3. | YT20M00004S003 | [1] | THERMOSTAT | KOB |
| 4. | 24100U759S28 | [2] | CLAMP | KOB |
| 5. | 24100U1188S12 | [2] | HOLDER | KOB |
| 6. | YT20M00004S006 | [2] | HOLDER | KOB |
| 7. | 24100U759S32 | [1] | CLAMP | KOB |
| 8. | YT20M00004S008 | [1] | EVAPORATOR | KOB, Serial Range: YH02-01301-YY02-03580 |
| 9. | YT20M00004S009 | [1] | CASE | KOB |
| 10. | YT20M00004S010 | [1] | CASE | KOB |
| 11. | YT20M00004S011 | [1] | CASE | KOB |
| 12. | YT20M00004S012 | [1] | ADAPTER | KOB, Serial Range: YH02-01301-YH02-01552 |
| 13. | YT20M00004S013 | [1] | ADAPTER | KOB, Serial Range: YH02-01301-YY02-03580 |
| 14. | YT20M00004S014 | [1] | PACKING | KOB |
| 15. | YT20M00004S015 | [1] | PACKING | KOB |
| 16. | YT20M00004S016 | [1] | PACKING | KOB |
| 17. | YT20M00004S017 | [1] | BRACKET | KOB |
| 18. | YT20M00004S018 | [1] | CLAMP | KOB |
| 19. | YT20M00004S019 | [1] | PLATE | KOB |
| 20. | YT20M00004S020 | [2] | LEVER | KOB |
| 21. | YT20M00004S021 | [1] | LEVER | KOB |
| 22. | YT20M00004S022 | [1] | LEVER | KOB |
| 23. | YT20M00004S023 | [3] | LEVER | KOB |
| 24. | YT20M00004S024 | [3] | LEVER | KOB |
| 25. | YT20M00004S025 | [1] | CAM | KOB |
| 26. | YT20M00004S026 | [1] | ROD | KOB |
| 27. | YT20M00004S027 | [1] | ROD | KOB |
| 28. | YT20M00004S028 | [1] | ROD | KOB |
| 29. | YT20M00004S029 | [1] | DAMPER | KOB |
| 30. | YT20M00004S030 | [1] | DAMPER | KOB |
| 31. | YT20M00004S031 | [1] | DAMPER | KOB |
| 32. | YT20M00004S032 | [1] | DAMPER | KOB |
| 33. | YT20M00004S033 | [1] | DAMPER | KOB |
| 34. | YT20M00004S034 | [1] | DAMPER | KOB |
| 35. | YT20M00004S035 | [1] | RADIATOR, HEATER | KOB |
| 36. | YT20M00004S036 | [1] | CONTROL | KOB |
| 37. | YN20M00016S015 | [1] | RELAY | KOBA/C blower motor (4 spade relay) Superseded by part number: YN20M00107S019 |
| 38. | YT20M00004S038 | [1] | CLAMP | KOB |
| 39. | YT20M00004S039 | [1] | BAND | KOB |
| 40. | YT20M00004S040 | [1] | CAP | KOB |
| 41. | YT20M00004S041 | [1] | HARNESS | KOB |
| 42. | YT20M00004S042 | [1] | RESISTOR | KOB |
| 43. | YT20M00004S043 | [1] | CASE | KOB |
| 44. | YT20M00004S044 | [1] | CASE | KOB |
| 45. | YT20M00004S045 | [2] | BRACKET | KOB |
| 46. | YT20M00004S046 | [1] | HOSE | KOB |
| 47. | YT20M00004S047 | [1] | ELECTRIC BLOWER | KOB |
| 48. | YT20M00004S048 | [1] | CASE | KOB |
| 49. | YT20M00004S049 | [1] | CASE | KOB |
| 50. | YT20M00004S050 | [1] | ELEMENT | KOB(not HEPA) Superseded by part number: YT20M00004S050P |
| 51. | YT20M00004S051 | [1] | LEVER | KOB |
| 52. | YT20M00004S052 | [1] | LEVER | KOB |
| 53. | YT20M00004S053 | [1] | DAMPER | KOB |
| 54. | YT20M00004S054 | [1] | PLATE | KOB Superseded by part number: YT20M01077P1 |
| 55. | YT20M00004S055 | [1] | SENSOR | KOB Superseded by part number: YT52S00003F1 |
| 56. | YT20M00004S056 | [1] | BOLT | KOB |
| 57. | YT20M00004S057 | [1] | GASKET | KOB |
| 58. | YT20M00004S058 | [1] | O-RING | KOB Superseded by part number: 2445Z1604D4 |
| 59. | YT20M00004S059 | [1] | O-RING | KOB Superseded by part number: 2445Z1604D5 |
| 60. | YT20M00004S060 | [6] | SCREW | KOB |
| 61. | YT20M00004S061 | [13] | SCREW | KOB |
| 62. | YT20M00004S062 | [30] | SCREW | KOB |
| 63. | YT20M00004S063 | [3] | BOLT | KOB |
| 64. | YT20M00004S064 | [9] | SCREW | KOB |
| 65. | YT20M00004S065 | [1] | SCREW | KOB |
| 66. | YT20M00004S066 | [2] | CAPSCREW | KOBSCREW |
| 67. | YT20M00004S067 | [4] | SCREW | KOB |
| 68. | YT20M00004S068 | [1] | EVAPORATOR | KOB, Start Serial: YH02-01553 |
| 69. | YT20M00004S069 | [1] | ADAPTER | KOB, Start Serial: YH02-01553 |
| 70. | YT20M00004S070 | [1] | ADAPTER | KOB, Start Serial: YH02-01553 |
| . . | YT20M00004R100 | [1] | REPAIR KIT | KOBREPAIR KIT CONSISTS OF REF 68,69 & 70, Start Serial: YH02-01553 |
