纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (04-027-00[01]) - BATTERIES New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
556 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 150801A1 | [2] | DRY BATTERY | SUM Superseded by part number: 150803A1 |
| 2. | 158403A1 | [2] | TERMINAL CONNECTOR | SUM |
| 3. | 150455A1 | [2] | TERMINAL CONNECTOR | SUM |
| 4. | 150803A1 | [2] | BATTERY, DRY | SUM Superseded by part number: 150803A2, 150803A2, BHC4DAW |
| 5. | 150360A1 | [1] | CAP | SUM Superseded by part number: 166116A1 |
| 6. | 166116A1 | [1] | DUST CAP | SUM |
| 7. | 166117A1 | [1] | DUST CAP | SUM |
| 8. | KHR2636 | [1] | CAP | SUM |
| 9. | 161011A1 | [1] | SUPPORT | SUM |
| 10. | 152821A1 | [2] | BOLT,Spcl, Hex, M10 x 270mm | SUM |
| 11. | 140028 | [2] | WASHER,10.2mm ID x 18.1mm OD x 2.2mm Thk | NH |
| 12. | 150409A1 | [2] | WASHER | SUM10,5 x 21 x 3,2 mm |
