神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (04-012) - VALVE ASSY, SOLENOID Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
298 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY35V00006F1 | [1] | VALVE | KOBASSY, SOLENOID |
| 101. | YX35V00002S101 | [1] | BODY | KOB |
| 151. | 2441U722S490 | [10] | PLUG | KOB1/16" NPTF |
| 171. | YX35V00002S171 | [14] | SCREW,Hex Socket Head, M5 x 12mm | KOBM05x0.8x12mm Superseded by part number: ZS23C05012 |
| 601. | YT35V00012F1 | [3] | SOLENOID VALVE | KOBASSY SEE P. YT35V00012 P2 Cut, Travel Straight, P1 Cut/Arm Conflux |
| 602. | YB35V00005F1 | [1] | SOLENOID VALVE | KOBASSY, SOLENOID SEE P. YB35V00005 Arm Var. Recirculation Superseded by part number: YN35V00048F1 |
| 701. | YT35V00013F1 | [2] | SOLENOID VALVE | KOBASSY, SOLENOID SEE P. YT35V00013 Travel 2 Speed, Lever Lock Superseded by part number: YN35V00061F1 |
| 702. | YT35V00014F1 | [1] | CARTRIDGE | KOBASSY SEE P. YT35V00014 Swing Parking Brake |
| 901. | YA35V00001S901 | [1] | PLATE | KOBNAME |
