现代零件查询R290LC-7 PILOT HYD PIPING(CONTROL 3, #1177-)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
299 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
UPPER HYD PIPING-BASE
|
|
| 9. |
X400-062019
|
[2] |
HOSE ASSY-SYNFLEX,ORFS
|
|
| 14. |
X400-062067
|
[2] |
HOSE ASSY-SYNFLEX,ORFS
|
|
| 15. |
X400-062072
|
[1] |
HOSE ASSY-SYNFLEX,ORFS
|
|
| 16. |
X400-062074
|
[1] |
HOSE ASSY-SYNFLEX,ORFS
|
|
| 21. |
31N6-25070
|
[1] |
FILTER-LAST GUARD
|
|
| 22. |
31N7-22100
|
[2] |
ELBOW 90-LONG,ORFS
|
|
| 24. |
X500-110002
|
[2] |
CONNECTOR-ORFS
|
|
| 25. |
X500-110011
|
[2] |
CONNECTOR-ORFS
|
|
| 27. |
X520-110002
|
[2] |
ELBOW-90,ORFS
|
|
| 28. |
X520-110011
|
[2] |
ELBOW-90,ORFS
|
|
| 33. |
S631-011004
|
[6] |
O-RING
|
|
| 34. |
S631-014004
|
[4] |
O-RING
|
|
| 36. |
S621-012001
|
[12] |
O-RING,ORFS
|
|
| 39. |
S037-103026
|
[4] |
BOLT-W/WASHER
|
|
