神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (09-044[02]) - MOTOR ASSY (SWING) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
327 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YX15V00004F1 | [1] | MOTOR | KOBASSY (SWING) Superseded by part number: YX15V00005F3 |
| . . | YX15V00004F2 | [1] | MOTOR | KOB(SWING) Superseded by part number: YX15V00005F3 |
| . . | YX15V00004F3 | [1] | HYDRAULIC MOTOR | KOBASSY (SWING) Superseded by part number: YX15V00005F3 |
| 10. | YX15V00004S010 | [1] | ROLLER BEARING | KOB(FOR F2&F3) |
| 11. | YW30V00001S157 | [2] | PLUG | KOB(FOR F2&F3) |
| 12. | YY22V00007F1 | [2] | VALVE | KOBASSY, RELIEF SEE .YY22V00007 (FOR F2&F3) |
| 13. | YV15V00002S013 | [1] | O-RING | KOBO-RING(FOR F3 ONLY) |
| 51. | YX22V00001F1 | [2] | VALVE | KOBVALVE ASSY, RELIEF SEE P. YX22V00001 (FOR F1 ONLY) |
| 101. | YX15V00004S101 | [1] | SHAFT | KOB |
| 106. | 2441U789S106 | [3] | SPACER | KOB |
| 111. | YX15V00004S111 | [1] | CYLINDER | KOB |
| 113. | 2441U789S113 | [1] | BUSHING | KOB |
| 114. | 2441U789S114 | [1] | SPRING | KOB |
| 116. | 2441U789S116 | [12] | PUSH ROD | KOB |
| 117. | 2441U789S117 | [2] | SPACER | KOB |
| 121. | NSS | [9] | NOT SOLD SEPARAT | CONPISTON |
| 122. | NSS | [9] | NOT SOLD SEPARAT | CONSHOE |
| 123. | 2441U789S123 | [1] | PLATE | KOB |
| 124. | 2441U789S124 | [1] | PLATE | KOBSHOE |
| 131. | YX15V00004S131 | [1] | PLATE | KOBVALVE |
| 301. | YX15V00004S301 | [1] | BODY | KOB |
| 303. | NSS | [1] | NOT SOLD SEPARAT | CONBODY |
| 304. | 2441U789S304 | [1] | COVER | KOB |
| 351. | YX15V00004S351 | [2] | SPOOL | KOBPLUNGER |
| 355. | YX15V00004S355 | [2] | SPRING | KOB |
| 390. | 2437U407S981 | [1] | LABEL | KOBNAME PLATE |
| 391. | 2437U407S983 | [2] | RIVET | KOBPIN |
| 401. | ZS23C16075 | [4] | SCREW,Hex Socket Head, M16 x 75mm | KOBM16x2.0x75mm |
| 432. | ZR16X03500 | [2] | RING | KOBRetaining -- ID 32.20 x OD 35 x Th 1.6mm |
| 433. | 2436U1318S836 | [1] | RING | KOB |
| 437. | ZR26X08000 | [1] | SNAP RING | KOBRetaining -- ID 80 x OD 85.5 x Th 2.5mm |
| 438. | ZR26X04200 | [1] | RETAINER | KOBRING |
| 443. | YX15V00004S443 | [1] | ROLLER BEARING | KOB |
| 444. | 2441U789S444 | [1] | ROLLER BEARING | KOB(FOR F1 ONLY) Superseded by part number: YX15V00004S010 |
| 451. | NSS | [2] | NOT SOLD SEPARAT | CONPIN |
| 464. | 2441U667S466 | [3] | PLUG | KOB1/4" PF, (FOR F1 ONLY) |
| 469. | 2436U1265S551 | [2] | PLUG | KOB |
| 471. | ZD12G08000 | [1] | O-RING,79.40mm ID x 85.60mm OD x 3.10mm | KOBID 79.40 ± 0.69 x OD 85mm |
| 472. | 2441U825S472 | [1] | O-RING | KOB(FOR F1&F2 ONLY) |
| 485. | ZD12P01100 | [3] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 488. | ZD12P02000 | [2] | O-RING,2.4mm Thk x 19.8mm ID, 90 Duro | KOBID 19.80 ± 0.22 x OD 24mm |
| 491. | 2441U564S491 | [1] | OIL SEAL | KOB |
| 702. | 2441U789S702 | [1] | PISTON | KOBBRAKE |
| 706. | 2441U825S706 | [1] | O-RING | KOB |
| 707. | 2415U188S706 | [1] | O-RING | KOB |
| 712. | 2441U789S712 | [20] | SPRING | KOB |
| 742. | YX15V00004S742 | [3] | PLATE | KOBFRICTION |
| 743. | YX15V00004S743 | [4] | PLATE | KOBSEPARATOR |
| 980. | YN15V00002S984 | [1] | PLUG | KOB |
| 981. | LQ15V00001S983 | [1] | PLUG | KOBPLUG |
| 982. | LQ15V00001S982 | [1] | PLUG | KOB |
| 992. | ZE82T08000 | [1] | PLUG | KOB1/2" PT |
| 993. | ZE82T04000 | [1] | PLUG | KOB1/4" PT |
| . . | YX15V00004R100 | [1] | REPAIR KIT | KOBCONSISTS OF ITEM 121X9, 122X9 |
| . . | YX15V00004R200 | [1] | REPAIR KIT | KOBCONSISTS OF ITEM 303X1, 451X2 |
| . . | YX15V00004R300 | [1] | REPAIR KIT | KOBCONSISTS OF ITEM 471X1, 472X1, 485X2, 488X2, 491X1, 706X1, 707X1(FOR F1&F2 ONLY) |
| . . | YV15V00002R400 | [1] | KIT | KOBREPAIR CONSISTS OF ITEM 13X1, 471X1, 485X2, 488X2, 491X1, 706X1, 707X1(FOR F3 ONLY) |
