纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (05-019-00[01]) - GUIDE PULLEY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
980 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KUA0288 | [1] | FLEETING PULLEY | SUM |
| 1.01. | KUA0325 | [1] | FRONT IDLER | SUM Superseded by part number: KUA10450 |
| 1.02. | KUA0337 | [1] | IDLER | SUM Superseded by part number: KUA10120 |
| 1.03. | KUA0338 | [1] | SHAFT | SUM |
| 1.04. | KUA0339 | [1] | BRACKET | SUM |
| 1.05. | KUA0340 | [1] | BRACKET | SUM |
| 1.06. | KUA0341 | [2] | BUSHING | SUM |
| 1.07. | KUA0342 | [2] | SEAL | SUM |
| 1.08. | CAD0064 | [2] | O-RING | SUM Superseded by part number: 154759A1 |
| 1.09. | KUA0343 | [2] | PIN | SUM |
| 1.1. | KUA0344 | [1] | PLUG | SUM |
| 1.11. | KUA0345 | [1] | O-RING | SUM |
| 1.12. | KUA0326 | [1] | CYLINDER ASSY. | SUM |
| 1.13. | KUA0329 | [1] | CYLINDER | SUM |
| 1.14. | KUA0330 | [1] | PISTON | SUM |
| 1.15. | KUA0331 | [1] | HOUSING | SUM |
| 1.16. | KUA0332 | [1] | SCRAPER RING | SUM |
| 1.17. | KUA0333 | [1] | SEAL | SUM |
| 1.18. | 154796A1 | [1] | O-RING | SUM |
| 1.19. | KUA0334 | [1] | O-RING | SUM |
| 1.2. | KUA0335 | [6] | BOLT | SUM |
| 1.21. | 183-108VR | [6] | SPRING WASHER | SUM |
| 1.22. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 1.23. | 102R020Y140R | [8] | BOLT | SUM |
| 1.24. | 150817A1 | [8] | WASHER,21mm ID x 40mm OD x 4.5mm Thk | SUM |
| 1.25. | KUA0327 | [1] | GUIDE | SUM |
| 1.26. | 108R010Y020R | [4] | BOLT | SUM |
| 1.27. | KUA0328 | [1] | BOLT | SUM |
| 2. | 150107A1 | [1] | LUBE NIPPLE | SUM |
