现代零件查询R290LC-7 TRAVEL HYDRAULIC PIPING(#1215)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
349 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
TRAVEL HYD PIPING
|
|
| 3. |
31N1-40970
|
[1] |
GASKET
|
|
| 4. |
P950-167344FL
|
[4] |
HOSE ASSY-ORFSXFLG
|
|
| 5. |
P930-082052
|
[2] |
HOSE ASSY-ORFS 0X90
|
|
| 6. |
X410-042058
|
[2] |
HOSE ASSY-SYNFLEX,ORFS
|
|
| 7. |
X511-104513
|
[2] |
CONNECTOR-ORFS
|
|
| 8. |
31N8-40190
|
[2] |
CONNECTOR-ORFS.LONG
|
|
| 9. |
32E9-00801
|
[4] |
FLANGE WA
|
|
| 10. |
X810-065151
|
[1] |
TEE-B/TYPE,ORFS
|
|
| 11. |
X810-085353
|
[1] |
TEE-B/TYPE,ORFS
|
|
| 12. |
P173-160104
|
[8] |
FLANGE-SPLIT
|
|
| 13. |
Y171-024004
|
[8] |
O-RING
|
|
| 14. |
S017-24065A
|
[36] |
BOLT-HEX
|
|
| 15. |
S037-123522
|
[4] |
BOLT-W/WASHER
|
|
| 16. |
S109-100306
|
[16] |
BOLT-SOCKET
|
|
| 17. |
S441-240002
|
[36] |
WASHER-HARDENED
|
|
| 18. |
S551-050203
|
[5] |
CLAMP-BAND
|
|
| 19. |
S621-014001
|
[4] |
O-RING,ORFS
|
|
| 20. |
S621-021001
|
[4] |
O-RING,ORFS
|
|
| 21. |
S631-011004
|
[2] |
O-RING
|
|
| 22. |
S631-014004
|
[1] |
O-RING
|
|
| 23. |
S631-018004
|
[3] |
O-RING
|
|
| 24. |
S109-120356
|
[16] |
BOLT-SOCKET
|
|
| 25. |
S760-102200
|
[2] |
GROMMET
|
|
| 26. |
S760-151224
|
[2] |
GROMMET
|
|
| 27. |
S621-011001
|
[4] |
O-RING,ORFS
|
|
