纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (07-007-00[01]) - HYDRAULIC MOTOR - TRAVEL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
295 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | KUA0282 | [1] | MOTOR, HYDRAULIC | SUM |
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 10. | 156109A1 | [2] | SPRING SEAT | SUM |
| 11. | LG00082 | [2] | SPRING | SUM |
| 12. | LR00736 | [2] | BUSHING | SUM |
| 55. | LJ00120 | [2] | CHECK VALVE | SUM |
| 56. | LG00080 | [2] | SPRING | SUM |
| 57. | LK00066 | [2] | PLUG | SUM |
| 58. | 154523A1 | [2] | O-RING | SUM |
| 61. | 161773A1 | [6] | PLUG | SUM |
| 62. | 154467A1 | [6] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 63. | LK00332 | [1] | PLUG | SUM |
| 64. | 163548A1 | [7] | PLUG | SUM |
| 65. | LB00688 | [1] | SHAFT | SUM |
| 71. | LR00737 | [1] | PLATE | SUM |
| 72. | LX00016 | [2] | BALL | SUM |
| 74. | LG00390 | [2] | COMPRESSION SPRING | SUM |
| 75. | LB00689 | [1] | CYLINDRICAL ROLLER BEARING | SUM |
| 76. | LB00690 | [1] | CYLINDRICAL ROLLER BEARING | SUM Superseded by part number: 5128935 |
| 77. | LH00293 | [1] | BUSHING | SUM |
| 78. | LA00599 | [1] | DOWEL | SUM |
| 79. | LG00391 | [9] | COMPRESSION SPRING | SUM |
| 80. | LR00092 | [2] | PLATE | SUM Superseded by part number: 164032A1 |
| 81. | LR00088 | [4] | PLATE | SUM |
| 82. | LR00091 | [3] | PLATE | SUM Superseded by part number: 156313A1 |
| 83. | LJ00867 | [1] | PISTON | SUM |
| 84. | 155218A1 | [1] | O-RING | SUM |
| 85. | LE00908 | [1] | BACK-UP RING | SUMRING, BACK-UP |
| 86. | 163954A1 | [1] | O-RING | SUM |
| 87. | LE00098 | [1] | BACK-UP RING | SUMRING, BACK-UP |
| 88. | LG00392 | [10] | COMPRESSION SPRING | SUM |
| 91. | 154969A1 | [1] | O-RING | SUM |
| 92. | 154463A1 | [4] | O-RING | SUM |
| 93. | 163553A1 | [2] | PLUG | SUM |
| 94. | 154503A1 | [2] | O-RING | SUM |
| 95. | LA00754 | [9] | BOLT,Spcl | SUM |
| 96. | 163547A1 | [2] | PLUG | SUM |
| 99. | LR00738 | [1] | PLATE | SUM |
