现代零件查询R290LC-7 BOOM HYD PIPING(6.25M, STD, #1811-)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
440 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
BOOM HYD PIPING-STD
|
|
| 4. |
31N8-51110
|
[1] |
PIPE ASSY
|
|
| 5. |
31N8-51120
|
[1] |
PIPE ASSY
|
|
| 5-1. |
Y171-024004
|
[1] |
O-RING
|
|
| 5-2. |
S109-100306
|
[4] |
BOLT-SOCKET
|
|
| 6. |
31N8-51130
|
[1] |
PIPE ASSY
|
|
| 7. |
31N8-51140
|
[1] |
PIPE ASSY
|
|
| 8. |
31N8-51150
|
[1] |
PIPE ASSY
|
|
| 9. |
31N8-51160
|
[1] |
PIPE ASSY
|
|
| 15. |
P700-167321FL
|
[1] |
HOSE ASSY-FLG 0X90
|
|
| 16. |
P680-167325FL
|
[1] |
HOSE ASSY-FLG
|
|
| 19. |
34E7-03510
|
[18] |
GROMMET
|
|
| 23. |
31N8-51170
|
[2] |
CLLAMP-PIPE
|
|
| 24. |
31E7-0175
|
[12] |
CLAMP
|
|
| 24. |
31E7-01750
|
[12] |
CLAMP ASSY
|
|
| 25. |
31E7-01710
|
[12] |
CLAMP
|
|
| 25. |
31E7-01711
|
[12] |
CLAMP ASSY
|
|
| 26. |
P173-160104
|
[22] |
FLANGE-HYD,SPLIT
|
|
| 27. |
31E9-01320
|
[2] |
FLANGE-SPLIT
|
|
| 28. |
S017-16080A
|
[2] |
BOLT-HEX(COATING)
|
|
| 30. |
S037-123522
|
[24] |
BOLT-W/WASHER
|
|
| 31. |
S109-100306
|
[56] |
BOLT-SOCKET
|
|
| 32. |
Y171-024004
|
[14] |
O-RING
|
|
| 33. |
S441-160002
|
[2] |
WASHER-HARDENED
|
|
| 34. |
S651-810002
|
[2] |
NIPPLE-GREASE
|
|
