| 1. |
87477567
|
[1] |
FORK
|
ZED
|
| 1. |
87477560
|
[1] |
FORK
|
ZED
|
| 1. |
87680323
|
[1] |
FORK
|
ZED
|
| 1. |
87680325
|
[1] |
FORK
|
ZED
|
| 1. |
87680327
|
[1] |
FORK
|
ZED
|
| 2. |
84068874
|
[1] |
TUBE
|
ZED
|
| 2. |
84068873
|
[1] |
ANGLE BAR
|
ZED
|
| 3. |
84074031
|
[1] |
SHAFT
|
ZED
Superseded by part number: 84068096
|
| 3. |
84074032
|
[1] |
SHAFT
|
ZED
Superseded by part number: 84068097
|
| 4. |
84053926
|
[1] |
HYD CONNECTOR
|
ZED
|
| 5. |
321204
|
[2] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 6. |
86508570
|
[1] |
BOLT,Hex, M6 x 80mm OAL, Cl 8.8
|
NH
|
| 7. |
353308
|
[5] |
NUT,M6 x 1.0, Cl 8
|
NH
|
| 8. |
120100
|
[4] |
BOLT,M6 x 20mm, Cl 8.8
|
NH
|
| 9. |
84043413
|
[2] |
COVER PLATE
|
ZED
|
| 10. |
84100982
|
[2] |
CANVAS
|
ZED
|
| 11. |
84320647
|
[2] |
BUSHING,17mm ID x 30mm OD x 27.5mm L
|
ZED
|
| 12. |
87679146
|
[1] |
ARM
|
ZED
, Serial Range: -C927 Superseded by part number: 84524109
|
| 12. |
84524109
|
[1] |
ARM
|
ZED
, Start Serial: D928
|
| 13. |
87679147
|
[1] |
ARM
|
ZED
, Serial Range: -C927 Superseded by part number: 84524112
|
| 13. |
84524112
|
[1] |
ARM
|
ZED
, Start Serial: D928
|
| 14. |
9838356
|
[4] |
WASHER,30.5mm ID x 40mm OD x 2mm Thk
|
ZED
, Serial Range: -C927
|
| 14. |
140108
|
[6] |
WASHER,31mm ID x 37mm OD x 1mm Thk
|
NH
, Start Serial: D928
|
| 15. |
397927
|
[2] |
SPHERICAL BEARING,30mm ID x 47mm OD x 22mm W
|
ZED
|
| 16. |
370003
|
[2] |
SNAP RING,M30, External
|
NH
|
| 17. |
355259
|
[2] |
BOLT,Hex, M16 x 65, 8.8
|
ZED
|
| 18. |
325594
|
[2] |
WASHER,M17 x 40mm OD x 5mm Thk
|
ZED
|
| 19. |
86000441
|
[2] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 20. |
87391000
|
[1] |
RETAINER
|
ZED
|
| 21. |
84068861
|
[1] |
SPRING
|
ZED
|
| 22. |
370024
|
[1] |
CIRCLIP,M20, Ext
|
NH
|
| 23. |
378247
|
[1] |
WASHER,21mm ID x 39mm OD x 3mm Thk
|
ZED
|
| 24. |
300502
|
[4] |
HEX SOC SCREW,FLAT, M12 x 1.75 x 40mm, Cl 8.8
|
ZED
|
| 25. |
100038
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 26. |
80140184
|
[1] |
WASHER,31mm ID x 50mm OD x 3mm Thk
|
ZED
|
| 27. |
536632
|
[6] |
BOLT
|
MKT
SHEAR BOLT Superseded by part number: 86508619
|
| 28. |
100037
|
[6] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 29. |
140048
|
[8] |
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
|
NH
|
| 30. |
84806913
|
[1] |
HUB
|
ZED
|
| 31. |
84806307
|
[1] |
DISC
|
ZED
|
| 32. |
84806287
|
[1] |
HUB
|
ZED
|
| 33. |
43168
|
[8] |
BOLT,Hex, M16 x 40mm, Cl 8.8
|
NH
Superseded by part number: 86509867
|
| 34. |
87748701
|
[2] |
RING
|
ZED
, Serial Range: -C927 Superseded by part number: 84523741
|
| 34. |
84523741
|
[2] |
RING
|
ZED
, Start Serial: D928
|
| 35. |
84277163
|
[2] |
CIRCLIP
|
ZED
, Start Serial: D928
|
