神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (02-023[00]) - CYLINDER ASSEMBLY, DOZER TILT (YY01VU0005F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
266 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY01VU0005F1 | [1] | CYLINDER,Double Acting, 50.8mm Rod, 127mm Stroke | KOBAssembly, Tilt Dozer -- Incls. Refs. 1-18 |
| 1. | NA | [1] | NOT SERVICED | FORTube, Cylinder |
| 2. | NA | [1] | NOT SERVICED | FORRod, Cylinder |
| 3. | YY01VU0005S010 | [2] | BUSHING | KOB |
| 4. | YY01VU0005S011 | [1] | FITTING | KOBGrease |
| 5. | YY01VU0005S012 | [1] | FITTING | KOBGrease |
| 6. | YY01VU0005S013 | [2] | RING | KOBRetainer |
| 7. | YY01VU0005S014 | [1] | LOCK NUT | KOB |
| 8. | YY01VU0005S015 | [1] | PISTON | KOB |
| 9. | YY01VU0005S002 | [1] | HEAD | KOB |
| 10. | NSS | [1] | NOT SOLD SEPARAT | CONWiper, (Part of kit YY01VU0005R100) |
| 11. | NSS | [1] | NOT SOLD SEPARAT | CONO-Ring, (Part of kit YY01VU0005R100) |
| 12. | NSS | [2] | NOT SOLD SEPARAT | CONRing, Wear (Part of kit YY01VU0005R100) |
| 13. | NSS | [2] | NOT SOLD SEPARAT | CONRing, Wear (Part of kit YY01VU0005R100) |
| 14. | NSS | [1] | NOT SOLD SEPARAT | CONO-Ring, (Part of kit YY01VU0005R100) |
| 15. | NSS | [1] | NOT SOLD SEPARAT | CONRing, Back-up (Part of kit YY01VU0005R100) |
| 16. | NSS | [1] | NOT SOLD SEPARAT | CONO-Ring, (Part of kit YY01VU0005R100) |
| 17. | NSS | [1] | NOT SOLD SEPARAT | CONSeal, (Part of kit YY01VU0005R100) |
| 18. | NSS | [1] | NOT SOLD SEPARAT | CONSeal, (Part of kit YY01VU0005R100) |
| K. | YY01VU0005R100 | [1] | SEAL KIT | KOB(Contain items marked with NSS) |
