现代零件查询R290LC-7 ARM HYDRAULIC PIPING(4.6M)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
940 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
ARM HYD PIPING(4.6M)
|
|
| 2. |
31EM-60140
|
[2] |
BLOCK
|
|
| 3. |
31N8-60710
|
[4] |
HOSE ASSY-FLG,0X90L
|
|
| 3. |
31N8-60711
|
[1] |
HOSE ASSY-FLG,0X90L
|
|
| 4. |
P840-042050
|
[1] |
HOSE ASSY-SYN THD
|
|
| 5. |
P840-042093
|
[1] |
HOSE ASSY-SYN THD
|
|
| 6. |
P860-042065
|
[1] |
HOSE ASSY-SYN 0X90
|
|
| 7. |
P173-120102
|
[16] |
FLANGE-SPLIT
|
|
| 8. |
31NB-50280
|
[1] |
ELBOW-90
|
|
| 9. |
P010-430011
|
[3] |
CONNECTOR
|
|
| 10. |
31N8-50370
|
[3] |
CLAMP
|
|
| 11. |
31N8-50380
|
[2] |
CLAMP-HOSE
|
|
| 12. |
31N8-50390
|
[3] |
CLAMP
|
|
| 13. |
Y171-019004
|
[8] |
O-RING
|
|
| 14. |
S035-062022
|
[8] |
BOLT-W/WASHER
|
|
| 15. |
S109-100356
|
[32] |
BOLT-SOCKET
|
|
| 16. |
S109-100806
|
[4] |
BOLT-SOCKET
|
|
| 17. |
S651-810002
|
[4] |
NIPPLE-GREASE
|
|
| 18. |
E231-0207
|
[2] |
ELBOW-45
|
|
