神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (05-001) - FUEL LINES (AUTO AIR BREATH) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
795 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY21P00002F2 | [1] | LINE | KOBFUEL |
| 1. | VI8972186470 | [1] | OIL SEPARATOR | KOB |
| 2. | VI5154112231 | [2] | PIPE | KOB |
| 3. | VI9095720140 | [4] | PACKING | KOB |
| 4. | VI9099063251 | [1] | BOLT | KOB Superseded by part number: 87596570 |
| 5. | VI5157590270 | [1] | BOLT | KOB |
| 6. | 2444R2492D085 | [1] | HOSE | KOB850mm Long (33-15/32 in) |
| 7. | 2444R2492D150 | [2] | HOSE | KOB1500mm Long (59-3/64 in) |
| 9. | 2418Z1333D20 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 800mm Length | KOBProtective Plastic |
| 10. | 2418Z1333D6 | [2] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 1400mm Length | KOB |
| 12. | ZC16X01800 | [14] | CLIP | KOBClamp, Hose -- Min 12 x Max 22mm |
| 13. | PY01P01043D3 | [12] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 14. | PY01P01043D5 | [1] | CABLE TIE,301mm L | KOBWire Ties -- 292mm Long |
| 15. | ZS18C08025 | [2] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 16. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 17. | HX11Y04030DX | [1] | HOSE,6mm ID x 300mm L | KOB |
| 19. | YX21P01003P1 | [1] | GROMMET | KOB |
| 21. | YR22P00001P1 | [1] | PUMP | KOBFUEL |
| 22. | YJ21P01008P2 | [1] | FILTER | KOBFUEL Superseded by part number: VY12905255630 |
| 23. | YR21P01009P1 | [1] | ELEC CONNECTOR | KOB |
| 24. | YR21P01008P1 | [1] | HOSE | KOB |
| 25. | 2444R2492D095 | [1] | HOSE | KOB950mm Long (37-25/64 in) |
| 26. | HX11F05034DX | [1] | HOSE | KOB Superseded by part number: HX11F05040DX |
| 27. | HX11F05140DX | [1] | HOSE | KOB Superseded by part number: HX11F05160DX |
| 28. | 2418Z1333D2 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 900mm Length | KOBProtective Plastic |
| 29. | 2418Z1333D28 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 1300mm Length | KOBProtective Plastic |
| 30. | 2418Z1333D1 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 250mm Length | KOBProtective Plastic |
| 31. | ZS18C10025 | [1] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 32. | ZW16X10000 | [1] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 33. | 2432R225D14 | [1] | CLIP | KOBClamp, Single -- ID 46 x 84mm Long Superseded by part number: ZC46X46014 |
| 34. | PY01P01043D4 | [1] | CABLE TIE,4.80mm W x 251mm L | KOBWire Ties -- 249mm Long |
| 20. | YT21P01002F1 | [1] | ELEC CONNECTOR | KOBASSY |
| 20-1. | VI5154112250 | [1] | PIPE | KOBCONNECTOR |
| 20-2. | VI1096750231 | [1] | BOLT | KOB |
| 20-3. | VI1157590010 | [2] | O-RING | KOBPACKING Superseded by part number: VI9095720140 |
| 35. | VI8972136680 | [1] | ORIFICE | KOB |
