纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-055-03[01]) - HYDRAULIC CIRCUIT - PILOT CONTROL LINES WITH LOAD HOLD New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
120 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 8. | KRJ4336 | [2] | HYDRAULIC HOSE,9.50 mm ID x 2200.00 mm | SUM |
| 9. | 168025A1 | [2] | HYDRAULIC HOSE,9.50 mm ID x 1950.00 mm | SUM |
| 12. | KMJ2292 | [1] | ADAPTER | SUM |
| 13. | 162826A1 | [3] | ADAPTER | SUM |
| 23. | KHJ1345 | [2] | HYDRAULIC HOSE,9.52 mm ID x 2150.00 mm | SUM |
| 27. | 152747A1 | [2] | ADAPTER | SUM |
| 28. | 154467A1 | [1] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 29. | KHJ1078 | [2] | ADAPTER | SUM |
| 30. | 164107A1 | [2] | TEE,3/8" ORB x 3/8" - 19 NPT x 3/8" - 19 NPT | SUM |
| 31. | 154475A1 | [1] | O-RING | SUM |
| 68. | KUJ0320 | [1] | BRACKET | SUM |
| 76. | KHJ1460 | [1] | HYDRAULIC HOSE | SUM |
| 77. | KBJ2349 | [1] | HOSE | SUM |
| 78. | KRJ3932 | [1] | HOSE | SUM |
| 79. | KTJ1639 | [1] | HOSE | SUM |
| 80. | KHJ1973 | [1] | VALVE | SUM Superseded by part number: KHJ17120 |
| 81. | 827-8045 | [2] | BOLT,Hex, M8 x 1.25 x 45mm, Cl 10.9 | CAS Superseded by part number: 16044131 |
| 82. | 153081A1 | [2] | WASHER | SUM |
| 83. | KHJ1974 | [1] | TEE | SUM Superseded by part number: KHJ2773 |
| 85. | KHJ1576 | [1] | BRACKET | SUM |
| 86. | 166052A1 | [2] | BOLT | SUM Superseded by part number: 11106231 |
| 99. | KRJ4762 | [1] | HOSE | SUM |
| 100. | 159063A1 | [1] | HOSE | SUM |
| 101. | KRJ3894 | [1] | HOSE | SUM |
| 118. | KRJ4763 | [1] | HOSE | SUM |
| 119. | KRJ4764 | [1] | HOSE | SUM |
| 120. | KRJ4970 | [1] | HOSE | SUM |
| 121. | 159714A1 | [1] | HOSE,3450.00 mm | SUM |
