神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (01-001-01) - FRAME ASSY, UPP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
425 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YX52F00005F1 | [1] | FRAME | KOBUpper Frame Group |
| . . | YX52F00005F2 | [1] | Upper Frame Group | |
| 1. | YN52F01160P1 | [1] | SEAL | KOB |
| 2. | YN52F01159P1 | [1] | PLATE | KOB |
| 3. | 2416Z434 | [1] | PACKING | KOB |
| 4. | YX52F01071D1 | [1] | RUBBER | KOB Superseded by part number: YY52F01567D5 |
| 5. | YX52F01071D2 | [1] | RUBBER | KOB Superseded by part number: YY52F01567D5 |
| 6. | YJ21C01156D3 | [1] | RUBBER | KOB |
| 7. | ZC16X14800 | [1] | CLIP | KOB |
| 8. | ZC46X22011 | [1] | CLIP | KOB |
| 9. | ZS18C10025 | [7] | SCREW,Hex, M10 x 25mm | KOB |
| 10. | ZS13C16080 | [25] | CAPSCREW | KOBSCREW Quantity for YX52F00005F1 |
| 11. | 2420T4561D1 | [3] | BOLT | KOBQuantity for YX52F00005F1 Only |
| 12. | ZN18C10008 | [1] | NUT | KOB |
| 13. | YN52F01157P1 | [7] | SEAL | KOB |
| 14. | ZW26X10000 | [1] | LOCK WASHER | KOB |
| 15. | YX52F01047P1 | [1] | GROMMET | KOB |
| 18. | YX52F01050P1 | [1] | RUBBER | KOB |
| 19. | HS53C16080G1 | [1] | SCREW | KOBQuantity for YX52F00005F2 Only |
