神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (01-009) - CONTROL BOX ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
640 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY03M00020F1 | [1] | CONTROL BOX ASSY (PEDAL) | |
| . . | YY03M00020F2 | [1] | CONTROL BOX ASSY (HAND CONTROL) | |
| 1. | YY03M01023P2 | [1] | CONTROL | KOBBOX |
| 2. | ZN18C14011 | [1] | NUT | KOBM14x2.0mm |
| 3. | YT03M01102F1 | [1] | GRIP | KOBF1 ONLY Superseded by part number: PW03M01630F1 |
| 3-1. | YW03M01011P1 | [1] | KNOB | KOB Superseded by part number: YW03M01011P2 |
| 3-3. | YN03M01252P1 | [1] | SCREW | KOB |
| 3-4. | YT03M01101P1 | [1] | LEVER | KOB |
| 4. | ZM22C08025 | [4] | BOLT | KOBM08x1.25x25mm (Incls. Washer & Lockwasher) |
| 5. | YT03M01052P1 | [1] | BOOT | KOBF1 ONLY |
| 6. | YT03M01051P2 | [1] | PLATE | KOB |
| 7. | PM22C01020D5 | [1] | TRIM PANEL | KOB75mm Long (2-61/64 in) |
| 8. | YY03M01026P1 | [1] | BRACKET | KOB, Serial Range: YL04-00501-YL04-00504 |
| 9. | ZS18C06016 | [4] | SCREW,Hex, M6 x 16mm | KOBM06x1.0x16mm |
| 10. | ZW16X06000 | [4] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 11. | 2420Z699 | [1] | GROMMET | KOB |
| 12. | LF03M01008P1 | [1] | BELLOWS | KOBF2 ONLY |
| 13. | LF03M01004P1 | [1] | BOOT | KOBF2 ONLY |
| 14. | YB03M01003F3 | [1] | GRIP | KOBAssembly, (With 3 Switches for AUX Hyd) (F2 Only) |
| 14-2. | LF03M01005F3 | [1] | HANDLE | KOB(Used for Nibbler Open/Close) |
| 14-3. | YB03M01002P1 | [1] | LEVER | KOB |
| 14-4. | ZP26D05028 | [1] | PIN,5mm OD x 28mm L, Slotted | KOBSpring |
| 15. | PY01P01043D1 | [1] | CABLE TIE,4.80mm W x 122mm L | KOBF2 ONLY, Start Serial: YL05-00569 Superseded by part number: YT50C01100P1 |
