| . . | YY68H00063F1 | [1] | CONTROL LINES, REMOTE | |
| 1. | YT30V00008F2 | [2] | VALVE | KOBASSY SEE (C.P.M), Serial Range: YL04-00501-YL04-00555 Superseded by part number: YY30V00055F1 |
| . . | YY30V00055F1 | [2] | PILOT VALVE | KOBASSY SEE (C.P.M), Start Serial: YL05-00556 |
| 2. | HH25X04004G2 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| 3. | PH03M01250P1 | [3] | BOOT | KOB |
| 4. | ZH22X06000 | [10] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| 5. | ZH32X06000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 6. | 2420R537D140 | [1] | HOSE ASSY.,9.60mm ID x 1400mm L | KOB1400mm Long (55-7/64 in) |
| 7. | 2420R537D195 | [1] | HOSE,9.53mm ID x 1950mm L | KOB |
| 8. | 2420R349D145 | [3] | HOSE | KOB1450mm Long (57-5/64 in) Superseded by part number: HX21E04145DX |
| 9. | 2420R349D200 | [3] | HOSE ASSY. | KOB2000mm Long (78-3/4 in) |
| 10. | YV68H01010D4 | [1] | HOSE | KOB |
| 11. | YV68H01010D1 | [1] | HOSE | KOB |
| 12. | YV68H01010D2 | [1] | HOSE | KOB |
| 13. | YV68H01010D3 | [1] | HOSE | KOB |
| 14. | YX68H01006D1 | [1] | HOSE | KOB Superseded by part number: HX23L06360CR |
| 15. | YX68H01006D2 | [1] | HOSE | KOB |
| 16. | YX68H01006D3 | [1] | HOSE | KOB |
| 17. | YX68H01006D4 | [1] | HOSE | KOB |
| 18. | 2420R537D260 | [1] | HOSE,9.60mm ID x 2600mm L | KOB |
| 19. | YR68H01016D1 | [3] | HOSE | KOB |
| 20. | PY01P01043D3 | [3] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 21. | YT64H01029D4 | [1] | RUBBER | KOB |
| 22. | YT64H01029D7 | [1] | RUBBER | KOB |
| 23. | YT64H01029D8 | [1] | RUBBER | KOB |
| 24. | YT64H01029D6 | [1] | RUBBER | KOB |
| 25. | YX68H01004D1 | [1] | GROMMET | KOB |
| 26. | PY01P01043D6 | [4] | CABLE TIE,4.80mm W x 383mm L | KOBWire Ties -- 368mm Long |
| 27. | 2432R325 | [1] | CLIP | KOBID 69 x 25mm |
| 28. | ZS28C06025 | [12] | SCREW,Hex Socket Head, M6 x 25mm | KOBM06x1.0x25mm |
| 29. | ZW16X06000 | [12] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 30. | ZS18C10020 | [2] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm, Serial Range: YL04-00501-YL04-00555 |
| . . | ZS18C10020 | [3] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm, Start Serial: YL05-00556 |
| 31. | ZW16H10000 | [2] | WASHER | KOBID 11 x OD 24 x Th 3.2mm, Serial Range: YL04-00501-YL04-00555 |
| . . | ZW16H10000 | [4] | WASHER | KOBID 11 x OD 24 x Th 3.2mm, Start Serial: YL05-00556 |
| 32. | YV68H01011P1 | [1] | GROMMET | KOB |
| 33. | ZC48X16011 | [1] | CLIP | KOB |
| 35. | PU13E01010DL | [1] | TUBE | KOBID 15.2 x OD 19.5 x 1200mm Long |
| 36. | 2436U3059F2 | [1] | PILOT VALVE | KOBASSY SEE (C.P.M) |
| 37. | 2444T3288 | [1] | 45 ELBOW | KOB45° -- (Incls. O-Ring ZD12P01100) |
| 38. | ZH42X04000 | [5] | 45 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 45° -- (Incls. O-Ring 237-6004) |
| 39. | HH25R04004G5 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| 40. | 2444Z2525 | [3] | HYD CONNECTOR | KOB1/4"PFx35mm Long (Incls. O-Ring ZD12P01100) Superseded by part number: 72217408 |
| 41. | 2420R537D130 | [1] | HOSE,9.60mm ID x 1300mm L | KOB Superseded by part number: HX21E06130DX |
| 43. | 2420R349D175 | [1] | HOSE,6.35mm ID x 1750mm L | KOB |
| 44. | 2420R349D070 | [1] | HOSE,700.00 mm | KOB700mm Long (27-9/16 in) |
| 45. | PY01P01043D8 | [1] | CABLE TIE,102mm L | KOBWire Ties -- 368mm Long |
| 46. | 2414Z199D60 | [1] | PROTECTIVE SLEEVE | KOBHOSE |
| 47. | YN64H01018P1 | [1] | GROMMET | KOB |
| 48. | ZC46X46014 | [1] | CLIP | KOBClamp -- Ø46mm Single Cable, Start Serial: YL05-0556 |
| 49. | YN03H01434P1 | [1] | BUSHING | KOBSplit -- ID 36 x OD 46 x 70mm Long, Start Serial: YL05-0556 |
