沃尔沃零件查询TMD41B; D41B; TAMD41B; AD41B; AD41BJMiscellaneous EquipmentControl for Side Installation PC840EPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
388 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
853102
|
[1] |
Mounting kit
|
|
| 2. |
1140048
|
[1] |
Cover
|
|
| 3. |
852347
|
[1] |
Hand lever
|
|
| 4. |
853004
|
[1] |
Push button
|
|
| 5. |
955142
|
[4] |
Cross recessed screw
|
|
| 6. |
851601
|
[1] |
Control, control cable clips
|
|
| 7. |
852924
|
[1] |
Locking pin
|
|
| 8. |
17253
|
[2] |
Split pin
|
|
| 9. |
839638
|
[2] |
Cube
|
|
| 10. |
839664
|
[1] |
Screw
|
|
| 11. |
853423
|
[1] |
Retainer
|
|
| 12. |
946435
|
[1] |
Lock nut
|
|
| 13. |
940275
|
[1] |
Washer
|
|
| 14. |
855352
|
[1] |
Neutral position con
|
|
| 15. |
850200
|
[1] |
Toggle switch
|
|
| 16. |
946177
|
[2] |
Cross recessed screw
|
|
| 17. |
947536
|
[2] |
Hexagon nut
|
|
| 18. |
|
|
|
See group 3
|
