纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-077-03[01]) - HYDRAULICS CYLINDER, ARM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
600 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KUV0006 | [1] | HYDRAULIC CYLINDER | SUM |
| 5. | KUV0051 | [2] | HYDRAULIC HOSE,38.10 mm ID x 1550.00 mm | SUM |
| 6. | KTJ0169 | [8] | FLANGE | SUM |
| 7. | 862-16050 | [16] | HEX SOC SCREW,M16 x 50mm, Cl 12.9 | CASM16 x 50; 12.9 Superseded by part number: 9817243 |
| 8. | 168211A1 | [4] | O-RING | SUM |
| 9. | KUV0171 | [1] | HYD. TUBE,38.6 mm ID x 48.6 mm OD | SUM |
| 10. | KUV0172 | [1] | HYD. TUBE,38.6 mm ID x 48.6 mm OD | SUM |
| 11. | KUV0175 | [2] | CLAMP BRACKET | SUM |
| 12. | 827-16110 | [2] | BOLT,Hex, M16 x 2 x 110mm, Cl 10.9 | CAS Superseded by part number: 84036080 |
| 13. | 150814A1 | [2] | WASHER,17mm ID x 32mm OD x 4.5mm Thk | SUM |
