神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (01-013) - CONTROL LINES, REMOTE (NIBBLER & BREAKER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
619 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY68H00048F1 | [1] | LINE | KOB |
| 1. | 2420R349D320 | [1] | HOSE ASSY. | KOB3200mm Long (126 in) |
| 2. | 2420R349D290 | [1] | HYDRAULIC HOSE,6.35 mm ID x 2900.00 mm | KOB |
| 3. | 2420R349D040 | [1] | HOSE,6.35mm ID x 400mm L | KOB1/4" PF, 400mm Long (15-3/4 in) |
| 4. | 2444R1120D060 | [1] | HOSE | KOB600mm Long (23-5/8 in) |
| 5. | LC35V00004F2 | [1] | SOLENOID VALVE | KOB |
| 6. | YT68H01018P1 | [1] | BRACKET | KOB |
| 7. | YT68H01015P1 | [1] | SUPPORT | KOB |
| 8. | ZS18C10020 | [4] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 9. | ZW16X10000 | [4] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 10. | 2444Z2894 | [1] | 90 ELBOW | KOBElbow, 90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
| 11. | 2444Z4101 | [1] | HYD CONNECTOR | KOB1/4"PFx1/4"PFx63mm Long (Incls. O-Ring ZD12P01100) |
| 12. | ZH32X04000 | [3] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 13. | HH35X04004G3 | [1] | 90 ELBOW | KOB90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
