神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (01-017[01]) - PANEL ASSY, INSTRUMENT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
445 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY17M00010F1 | [1] | PANEL ASSY, INSTRUMENT | |
| 1. | YY17M00011F1 | [1] | PANEL ASSY (R.H) | |
| 1-1. | YY17M01013P1 | [1] | PANEL | KOBASSY |
| 1-2. | YN52S00032P1 | [1] | POTENTIOMETER | KOBCab Fan Control Switch - High/Low Superseded by part number: YN52S00032P2 |
| . . | YN52S00032S001 | [1] | POTENTIOMETER | KOBThrottle Potentiometer, Not Shown Superseded by part number: YN52S00032P2 |
| . . | YN52S00032S002 | [1] | KNOB | KOB Superseded by part number: YN52S00032S003 |
| 1-3. | YN50S00026F1 | [1] | IGNITION SWITCH | KOBAssembly, Key -- (Incls. Keys YN50S01010P1) |
| 1-3A. | YN50S01010P1 | [1] | SET OF 2 KEYS,Kobelco Branded | KOBKey - (Part of YN50S00026F1) |
| 2. | YT17M01001P1 | [1] | PANEL | KOB |
| 3. | YT17M01002P1 | [1] | PANEL | KOBCOVER |
| 4. | YT17M01003P1 | [1] | PANEL | KOBCOVER |
| 5. | YT17M01004P1 | [1] | PANEL | KOBCOVER |
| 6. | YT17M01005P1 | [1] | PANEL | KOBCOVER |
| 8. | YX17M01003P1 | [2] | BRACKET | KOB |
| 9. | 2420R1089D1 | [8] | BOLT,M5 x 10mm | KOBM05x0.8x10mm (Incls. Washer & Lockwasher) |
| 11. | YT54S00006P1 | [2] | SPEAKER | KOB |
| 12. | ZM46C05016 | [10] | BOLT,Phillip, M5 x 0.8 x 15mm | KOBM05x0.8x16mm (Incls. Washer & Lockwasher) |
| 13. | 2414T4530 | [1] | CAP | KOBSwitch -- 20x30mm |
| 15. | YT17M01031F1 | [1] | COVER ASSY | KOB |
| 15-1. | YT17M01028P1 | [1] | COVER | KOB |
| 15-2. | YT20M01008P1 | [1] | DUCT | KOB |
| 15-3. | YN20M01011P1 | [1] | GRILLE | KOB |
| 15-4. | 2421R180F1 | [1] | CIGARETTE LIGHTER | KOB Superseded by part number: YN81S00003P1 |
| 15-5. | YT03M01032P1 | [1] | TRAY ASSY. | KOB |
| 15-6. | 2414T4530 | [2] | CAP | KOBSwitch -- 20x30mm |
| 15-7. | ZS32T50014 | [3] | SCREW | KOBM05x14mm Self-Taper |
| 15-9. | YT03M01033S012 | [1] | BRACKET | KOB |
| 15-10. | YT03M01033S013 | [1] | BRACKET | KOB |
| 15-11. | ZS32T50010 | [1] | SCREW | KOBM05x10mm Self-Taper |
| 16. | ZM46C06016 | [4] | SCREW | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| 18. | ZM22C08016 | [3] | BOLT | KOBM08x1.25x16mm (Incls. Washer & Lockwasher) |
| 19. | ZS32T40008 | [8] | SELF-TAP SCREW | KOBM04x08mm Self-Taper |
| 20. | ZM46C05012 | [2] | BOLT | KOBM05x0.8x12mm (Incls. Washer & Lockwasher) |
| 21. | LB54S00001P1 | [1] | RADIO | KOB Superseded by part number: YN54S00074P1 |
| 22. | YY59S00003F1 | [1] | GAUGE | KOBCluster used for NA |
| 23. | YT17M01020P1 | [2] | INDICATOR | KOB |
| 24. | 2479U1190F7 | [1] | SWITCH | KOB(DECEL) |
| 25. | YT17M01017P2 | [1] | BRACKET | KOB |
| 26. | YT77S00001P1 | [1] | CONVERTER,24V In - 12V Out - 2.5A | KOB(DC-DC) Superseded by part number: YT77S00011P1 |
| 27. | ZM46C06012 | [2] | SCREW | KOBM06x1.0x12mm (Incls. Washer & Lockwasher) |
| 28. | YN20M01092D2 | [2] | BOLT | KOB |
| 29. | YT21C01141P1 | [2] | SHEET | KOB |
| 30. | YN17M01053P1 | [2] | NUT | KOB |
| 31. | ZW16K04000 | [8] | WASHER | KOBID 04 x OD 08 x Th 0.8mm |
| 32. | YT17M01013P1 | [4] | CAP | KOB |
| 33. | YT17M01014P1 | [1] | CAP | KOB |
| 34. | ZM46C06040 | [2] | BOLT | KOBM06x1.0x40mm (Incls. Washer & Lockwasher) |
| 36. | YT17M01019P2 | [1] | BRACKET | KOB |
| 37. | ZM22C10020 | [1] | BOLT | KOBM10x1.50x20mm (Incls. Washer & Lockwasher) |
| 38. | YN81S00001P1 | [1] | SOCKET | KOB(FOR 12V) |
| 39. | 2479U1190F32 | [1] | SWITCH | KOB |
| 40. | YN54S00012D1 | [1] | ANTENNA | KOBCORD |
| 44. | ZN18C06005 | [2] | NUT | KOBM06x1.0mm |
| 45. | ZW16X06000 | [2] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 46. | YT58S00006P1 | [1] | HOURMETER | KOBHour |
| 47. | YT17M01034P1 | [1] | HOLDER | KOB Superseded by part number: YT17M01034P2 |
| 48. | YT17M01032P1 | [2] | BOLT | KOB |
| 49. | YY17M01010D1 | [1] | RUBBER RING | KOB |
| 50. | YM03MU1012P1 | [1] | GRIP | KOB |
| 51. | 2479U1190F15 | [1] | SWITCH | KOB(DOZER) |
| 52. | 2479U1190F31 | [1] | SWITCH | KOBAutomatic Warm-Up |
