神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (01-020[02]) - HARNESS ASSY, UPP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
250 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY1300009F7 | [1] | HARNESS ASSY, UPP (STD) | |
| . . | YY13E00009F8 | [1] | HARNESS ASSY, UPP (JOHN DEERE) | |
| 1. | YX13E01006D1 | [1] | CABLE | KOB |
| 2. | 2486R89D5 | [1] | CABLE | KOB |
| 3. | YN13E01053D3 | [1] | CABLE | KOB350mm Long (13-49/64 in) |
| 4. | YX13E01020D1 | [1] | CABLE | KOB |
| 5. | YY13E01053P3 | [1] | HARNESS | KOB |
| 6. | LE13E01006P1 | [1] | HARNESS | KOB100mm Long (3-15/16 in) |
| 7. | ZN18C08007 | [1] | NUT | KOBM08x1.25mm |
| 8. | ZW26X08000 | [3] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 9. | 2432R233D1 | [2] | CLIP | KOB37x12x40mm |
| 10. | ZM61C06012 | [2] | BOLT | KOBM06x1.0x12mm (Incls. Washer & Lockwasher) |
| 11. | YX13E01015P1 | [1] | GROMMET | KOB |
| 12. | YX13E01012P1 | [1] | GROMMET | KOB |
| 13. | PY13E01039P1 | [1] | RUBBER | KOB |
| 14. | PY01P01043D4 | [3] | CABLE TIE,4.80mm W x 251mm L | KOBWire Ties -- 249mm Long, F7 Only |
| . . | PY01P01043D4 | [4] | CABLE TIE,4.80mm W x 251mm L | KOBWire Ties -- 249mm Long, F8 Only |
| 16. | ZW16X08000 | [2] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 17. | YX13E01016P1 | [1] | GROMMET | KOB |
| 20. | 2432R233D3 | [2] | CLIP | KOB50x16x60mm, F7 ONLY |
| . . | 2432R233D3 | [1] | CLIP | KOB50x16x60mm, F8 ONLY |
| 21. | ZS18C08016 | [3] | SCREW,Hex, M8 x 16mm | KOBM08x1.25x16mm, F7 Only |
| . . | ZS18C08016 | [2] | SCREW,Hex, M8 x 16mm | KOBM08x1.25x16mm, F8 Only |
| 22. | ZW16X10000 | [1] | WASHER | KOBID 10 x OD 21 x Th 2.0mm, F7 Only |
| 26. | YN13E01175P1 | [1] | GROMMET | KOB |
