87622708
|
[1] |
DIA KIT, HARVESTER
|
ATT
|
| 1. |
87026294
|
[2] |
SENSOR
|
GI
|
| 2. |
84159863
|
[1] |
SENSOR
|
ZED
|
| 3. |
84134704
|
[1] |
CONTROLLER
|
ZED
|
| 4. |
86977789
|
[4] |
BOLT,Hex, M6 x 1.0 x 35mm, Cl 8.8
|
ZED
|
| 5. |
322357
|
[14] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 6. |
9706755
|
[10] |
NUT,M6, Cl 8
|
NH
Superseded by part number: 86500688
|
| 7. |
9837692
|
[2] |
CLAMP,16.67mm ID, 13.46mm Bolt Hole, P Type
|
ZED
|
| 8. |
9512290
|
[5] |
RIVET,Pop, 4.8mm OD x 17.8mm L
|
ZED
|
| 9. |
86590413
|
[11] |
BASE,15.87mm W x 22.22mm OAL x 9.9mm Thk
|
ZED
|
| 10. |
445394
|
[11] |
RIVET,Pop, 3/16" x 1/2" OAL
|
ZED
Superseded by part number: 151-573
|
| 11. |
86566989
|
[38] |
CABLE TIE,208mm L
|
ZED
CABLE STRAP
|
| 12. |
86511824
|
[2] |
SCREW,Phillips Drive, Pan HD, M4 x 0.7 x 20mm, Cl 4.8
|
NH
|
| 13. |
322355
|
[2] |
BELLEVILLE WASHER,M4 Bolt Size x 10mm OD x 0.9mm Thk
|
NH
|
| 14. |
100012
|
[2] |
NUT,M4 x 0.7, Cl 8
|
NH
Superseded by part number: 57121
|
| 15. |
86508568
|
[4] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8
|
NH
|
| 16. |
84058832
|
[3] |
CLIP
|
ZED
|
| 17. |
445395
|
[1] |
RIVET,Pop, 4.8mm OD x 18.1mm L
|
IH
|
| 18. |
173011
|
[1] |
GROMMET,1” ID x 1.750” OD x .500” Tk
|
NH
|
| 19. |
9827902
|
[4] |
CLAMP,25.4mm, Coat, 10.3mm Bolt Hole, P Type
|
WIN
|
| 20. |
84184503
|
[1] |
WIRE HARNESS
|
ZED
|
| 21. |
84185072
|
[1] |
WIRE HARNESS
|
ZED
|
| 22. |
84460028
|
[1] |
WIRE HARNESS
|
ZED
|
| 23. |
84164654
|
[2] |
SENSOR
|
ZED
|
| 24. |
84247024
|
[1] |
WIRE CONNECTOR
|
ZED
Superseded by part number: 84068583, 84074642
|
| 25. |
87380352
|
[1] |
ELEC CONNECTOR
|
ZED
|
| 26. |
84264530
|
[1] |
PLATE
|
ZED
|
| 27. |
300506
|
[2] |
BOLT,Hex, M6 x 1 x 25mm, Cl 8.8, Full Thd
|
NH
Superseded by part number: 86977786
|
| 28. |
84320044
|
[1] |
FUSE,5 Amp
|
ZED
Superseded by part number: 87693742
|
