神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (10-017) - TURBOCHARGER SYSTEM Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
879 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | NSS | [1] | NOT SOLD SEPARAT | CONTURBOCHARGER SYSTEM |
| 1. | VI8972234280 | [1] | TURBOCHARGER | KOBASM (SEE FIG.10-018) |
| 2. | VI8943690230 | [1] | GASKET | KOBTURBOCHARGER TO EXH MANIF |
| 12. | VI8944762820 | [3] | STUD | KOBTURBOCHARGER (M8X25 L=36) Superseded by part number: VI8973780620 |
| 20. | VI8972234342 | [1] | TUBE | KOBPIPE, INL, TURBOCHARGER OUT |
| 77. | VI0287810250 | [2] | BOLT | KOBBOLT, INL DUCT (M10X25 FLANGE) |
| 97. | VI8943169910 | [2] | CLIP | KOBHOSE, TURBOCHARGER, INL (ID=50-69) |
| 133(A). | VI8972221210 | [1] | PIPE | KOBOIL DRAIN, TURBOCHARGER |
| 134(A). | VI8943690220 | [1] | PACKING | KOBGASKET, OIL PIPE, TURBOCHARGER DRAIN |
| 134(B). | VI8943706630 | [1] | GASKET | KOBOIL PIPE, TURBOCHARGER DRAIN |
| 148. | VI1093607820 | [1] | HOSE | KOBTURBOCHARGER, INL |
| 150. | VI8970614011 | [4] | NUT | KOBINL DUCT |
| 401. | VI0280806160 | [2] | BOLT | KOBBOLT, OIL PIPE, TURBOCHARGER (M6X16 FLANGE) Superseded by part number: VI0280506160 |
| 461. | VI9041108220 | [2] | STUD | KOBOIL PIPE, TURBOCHARGER |
| 462. | VI0911501080 | [2] | NUT | KOBOIL PIPE, TURBOCHARGER Superseded by part number: VI0911802080 |
