凯斯零件查询(LB333R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (9/08-12/12) (00.00LB022[01]) - MAINTENANCE PARTS, FLYWHEEL & SHEAR BOLTS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
630 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
853116
|
[2] |
TAPERED BEARING
|
ZED
Superseded by part number: 87555831
|
| 2. |
83931335
|
[1] |
BOLT,Hex, M10 x 1.5 x 75mm, Cl 8.8
|
ZED
Shear, Flywheel
|
| 2. |
86624979
|
[1] |
BOLT,Hex, M10 x 75mm, Cl 10.9
|
FAR
Shear, Flywheel
|
| 3. |
87695682
|
[1] |
SHEAR BOLT BUSHING,10.2mm ID x 31.7mm OD x 38mm L
|
ZED
|
| 4. |
100037
|
[1] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 5. |
87368630
|
[1] |
BRAKE BAND
|
ZED
Flywheel
|
| 5. |
87368632
|
[1] |
BRAKE BAND,75mm W x 3mm Thk
|
ZED
Flywheel
|
| 6. |
120062
|
[1] |
BOLT,Hex, M8 x 70mm, Cl 8.8
|
NH
Shear, Knotter drive Superseded by part number: 7120024
|
| 7. |
86629542
|
[1] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 8. |
536632
|
[1] |
BOLT
|
MKT
Shear, Stuffer Superseded by part number: 86508619
|
