| . . | YY03H00023F1 | [1] | LINE | KOBUPP |
| A2. | YX03H01074P1 | [1] | BUSHING | KOB |
| A3. | YX03H01075P1 | [1] | BUSHING | KOB |
| A6. | YY03H01050P2 | [1] | TUBE | KOB |
| A7. | YY03H01058P1 | [1] | SUPPORT | KOB |
| A8. | YY03H01059P1 | [1] | SUPPORT | KOB |
| A9. | ZG23F10012 | [7] | HYD CONNECTOR | KOB5/8"-3/4" PT (Incls. O-Ring ZD12P02400) |
| A9-1. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| A10. | ZG23F12012 | [1] | HYD CONNECTOR | KOB1 3/16" 12UN-3/4" PT x 48mm Long (Incls. O-Ring ZD12P02400) |
| A10-1. | ZD12P02400 | [1] | O-RING | KOB(Part of ZG23F12012), ID 23.70 ± 0.24 x OD 30mm |
| A11. | HG24F10012G3 | [4] | HYD CONNECTOR | KOB1"-14UNS - 3/4"PT x 90mm Long (Incls. O-Ring ZD12P02400) |
| A11-1. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| A12. | YX03H01046P1 | [3] | CLIP | KOBWire, Tie -- 564mm Long (22-13/64 in) |
| A13. | ZG33F10008 | [1] | 90 ELBOW,1"-14 UNS x PF 1/2" | KOB90° -- 1" -14UNS x 1/2" PF (Incls. O-Ring ZD12P01800) |
| A13-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| A14. | HG34F10008G1 | [1] | 90 ELBOW,1"-14 UNS x PF 1/2", O-Ring | KOB90° -- (Incls. O-Ring ZD12P01800) |
| A14-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| A15. | YT64H01029D9 | [1] | RUBBER | KOB |
| A16. | YY03H01089D2 | [1] | HOSE | KOB |
| A18. | YY03H01089D1 | [1] | HOSE | KOB |
| A19. | YX03H01094P1 | [1] | HOSE | KOB |
| A20. | YX03H01097P1 | [1] | HOSE | KOB |
| A21. | YX03H01096P1 | [1] | HOSE | KOB |
| A22. | YX03H01095P1 | [1] | HOSE | KOB |
| A23. | ZW16H10000 | [6] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| A24. | ZW16H12000 | [4] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| A25. | YN03H01169P1 | [1] | GROMMET | KOB |
| A26. | PY01P01043D8 | [2] | CABLE TIE,102mm L | KOBWire Ties -- 368mm Long, Serial Range: YH02-01301-YH02-01444 |
| A27. | YY03H01056D2 | [1] | HOSE | KOB, Serial Range: YH02-01301-YH02-01335 |
| A27. | YY03H01056D4 | [1] | HOSE | KOB, Start Serial: YH02-01336- |
| A28. | YX03H01045D6 | [1] | HOSE | KOB |
| A29. | YX03H01045D8 | [1] | HOSE | KOB |
| A30. | YY03H01056D1 | [1] | HOSE | KOB, Serial Range: YH02-01301-YH02-01335 |
| A30. | YY03H01056D3 | [1] | HOSE | KOB, Start Serial: YH02-01336- |
| A31. | LE03H01212D3 | [2] | TUBE | KOB |
| A32. | YX03H01045D3 | [2] | HOSE | KOB |
| A33. | YX03H01091P1 | [1] | RUBBER | KOB |
| A34. | ZD12A01600 | [19] | O-RING | KOBID 15.60 ± 0.12 x OD 19.16mm |
| A35. | ZD12A01800 | [1] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm |
| A36. | YN03H01244P1 | [2] | CLAMP | KOB |
| A37. | YX03H01089P1 | [1] | GROMMET | KOB |
| A38. | ZS18C10025 | [4] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| A39. | ZS18C10045 | [2] | SCREW,Hex, M10 x 45mm | KOBM10x1.50x45mm |
| A40. | ZS18C12045 | [3] | SCREW,Hex, M12 x 45mm | KOBM12x1.75x45mm |
| A41. | ZS18C12090 | [1] | SCREW,Hex, M12 x 90mm | KOBM12x1.75x90mm |
| A44. | YY64H01019D1 | [1] | RUBBER | KOB |
| A45. | YV03H01066P1 | [1] | BRACKET | KOB |
| A46. | YV03H01021P1 | [1] | CLAMP | KOB |
| A47. | YY03H01051P1 | [1] | TUBE | KOB |
| . . | YV19H00001F1 | [1] | LINE | KOBSWIVEL |
| B1. | HG33F10016G1 | [2] | ELBOW | KOB90° -- (Incls. O-Ring ZD12P02900) 56mm Long |
| B1-1. | ZD12P02900 | [1] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| B2. | HG34F10016G1 | [2] | ELBOW | KOB90° -- (Incls. O-Ring ZD12P02900) 100mm Long |
| B2-1. | ZD12P02900 | [1] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| B3. | YX19H01001P1 | [1] | ELEC CONNECTOR | KOB |
| B3-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| B4. | ZD12A01600 | [4] | O-RING | KOBID 15.60 ± 0.12 x OD 19.16mm |
