凯斯零件查询(LB333R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (9/08-12/12) (05.07[01]) - TANDEM AXLE WITHOUT BRAKES Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
293 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84214850
|
[1] |
FRONT AXLE
|
ZED
|
| 1. |
84214863
|
[1] |
FRONT AXLE
|
ZED
|
| 1. |
84214852
|
[1] |
REAR AXLE
|
ZED
|
| 1. |
84214864
|
[1] |
REAR AXLE
|
ZED
|
| 2. |
84041871
|
[16] |
BOLT
|
ZED
|
| 3. |
84807624
|
[2] |
SEAL
|
ZED
Superseded by part number: 84521823
|
| 4. |
84100483
|
[2] |
BALL BEARING,75mm ID x 130mm OD x 33.25mm W
|
ZED
Superseded by part number: 26800210
|
| 5. |
84100482
|
[2] |
RING
|
ZED
|
| 6. |
87354761
|
[2] |
HUB
|
ZED
|
| 7. |
84100484
|
[2] |
RING
|
ZED
|
| 8. |
84100485
|
[2] |
BALL BEARING,60mm ID x 110mm OD x 29.75mm W
|
ZED
Superseded by part number: 87622924
|
| 9. |
84045545
|
[16] |
WHEEL NUT
|
ZED
, Serial Range: -C859 Superseded by part number: 84288019
|
| 9. |
84288019
|
[16] |
WHEEL NUT
|
PLO
, Start Serial: D860
|
| 10. |
84212727
|
[2] |
COTTER PIN
|
ZED
|
| 11. |
84100486
|
[2] |
NUT
|
ZED
|
| 12. |
87354753
|
[2] |
COVER
|
ZED
Superseded by part number: 84521831
|
| 13. |
14301931
|
[12] |
HEX SOC SCREW,M8 x 1.25 x 10mm, Cl 10.9, Full Thd
|
LEC
|
| 14. |
84807540
|
[1] |
FRONT AXLE
|
ZED
(1 TO 13)
|
| 14. |
84807549
|
[1] |
FRONT AXLE
|
ZED
(1 TO 13)
|
| 14. |
84807541
|
[1] |
REAR AXLE
|
ZED
(1 TO 13)
|
| 14. |
84807550
|
[1] |
REAR AXLE
|
ZED
(1 TO 13)
|
| 15. |
84288018
|
[1] |
KIT
|
PLO
(9), (SET OF 16)
|
