神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (01-056) - CONDITIONER ASSY, AIR, P/N YV20M00003F3 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
878 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YV20M00003F3 | [1] | AIR CONDITIONER | KOBASSY |
| 1. | YT20M00009F1 | [1] | AIR CONDITIONER | KOBSEE FIG 01-056 |
| 3. | YX91V00002F2 | [1] | AIRCOND. COMPRESSOR | KOBSEE FIG 01-058 |
| 4. | YT20M01104F1 | [1] | PANEL | KOBSEE FIG 01-059 |
| 5. | YT95V00001F1 | [1] | FILTER ASSY | KOBSEE FIG 01-059 |
| 8. | YV96V00001F3 | [1] | RECEIVER-DRYER | KOBSEE FIG 01-057 Superseded by part number: YV96V00001F6 |
| 9. | YT20M01060P2 | [1] | CONDENSER | KOB |
