纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (09-103-00[01]) - BUCKET CONTROL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
460 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KUV0252 | [1] | POWER ARM | SUM |
| 2. | KUV0030 | [2] | BUSHING | SUM |
| 3. | KUV0035 | [2] | BUSHING | SUM |
| 4. | KHV0289 | [2] | SEAL | SUM |
| 5. | KHV0290 | [4] | SEAL | SUM |
| 6. | KUV0167 | [1] | LINKAGE YOKE | SUM |
| 7. | KUV0168 | [1] | LINKAGE YOKE | SUM |
| 8. | KUV0019 | [1] | PIN | SUM |
| 9. | KUV0020 | [1] | PIN | SUM |
| 10. | KUV0024 | [1] | PIN | SUM |
| 11. | KUV0021 | [1] | PIN | SUM |
| 12. | KUV0088 | [1] | BOLT | SUMM36 - 2 x 290 |
| 13. | 172R036VN | [6] | NUT | SUMM36 - 2 |
| 14. | 132R030W240N | [1] | BOLT,M30 x 2 x 240mm | SUMM30 - 2 x 240 |
| 15. | 172R030VR | [2] | NUT | SUMM30 |
| 16. | KUV0169 | [2] | BOLT | SUMM36 - 2 x 260 |
| 17. | 153630A1 | [4] | LUBE NIPPLE | SUM |
| 18. | KHV0293 | [4] | O-RING | SUM |
| 19. | KHV0292 | [2] | O-RING | SUM |
| 20. | KHV0297 | [1] | SHIM | SUM |
| 21. | KHV0296 | [1] | SHIM | SUM |
| 22. | KHV0294 | [2] | O-RING | SUM |
| 23. | KHV0295 | [2] | O-RING | SUM |
