纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (09-115-00[01]) - DECALS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
423 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | K4051597 | [2] | DECAL | P |
| 2. | L4051598 | [2] | DECAL | P |
| 3. | H7947565 | [4] | DECAL | P |
| 4. | 168101A1 | [1] | DECAL | SUM |
| 5. | 168102A1 | [1] | DECAL | SUM Superseded by part number: KHP11700 |
| 6. | 168104A1 | [1] | DECAL | SUM |
| 7. | 168109A1 | [1] | DECAL | SUM |
| 8. | 168110A1 | [1] | DECAL | SUM |
| 9. | 168111A1 | [1] | DECAL | SUM |
| 10. | 168112A1 | [1] | DECAL | SUM |
| 11. | 168400A1 | [4] | DECAL | SUM |
| 12. | 162936A1 | [4] | ADHESIVE STRIP | SUM Superseded by part number: 150108A1 |
| 13. | 168484A1 | [2] | ANTI-SKID STRIP | SUM |
| 14. | 162935A1 | [12] | ANTI-SKID STRIP | SUM |
| 15. | KHP1177 | [1] | DECAL | SUM |
| 16. | KHP1178 | [1] | DECAL | SUM |
| 17. | KHP1111 | [1] | LABEL | SUM |
| 18. | L2651565 | [1] | ADHESIVE | P |
| 19. | KHP1601 | [1] | DECAL | SUM |
| 21. | KHP1771 | [1] | LABEL | SUM |
