现代零件查询R290LC-7A ARM(2.50M, HEAVY DUTY)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
608 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
64N8-23000
|
[1] |
ARM ASSY
|
|
| 1. |
64N8-23010
|
[1] |
ARM WA
|
|
| 1. |
64N8-23012
|
[1] |
ARM WA
|
|
| 1. |
64N8-23010
|
[1] |
ARM WA
|
|
| 1. |
64N8-23012
|
[1] |
ARM WA
|
|
| 2. |
61Q6-04090
|
[2] |
BUSHING
|
|
| 3. |
61Q6-04080
|
[2] |
BUSHING
|
|
| 4. |
61EN-12320
|
[2] |
BUSHING-BRONZE
|
|
| 5. |
S700-090206
|
[2] |
DUST SEAL-DKIY TYPE
|
|
| 6. |
S700-080206
|
[2] |
DUST SEAL-DKIY TYPE
|
|
| 7. |
S700-100208
|
[2] |
DUST SEAL-DKIY TYPE
|
|
| 8. |
S651-810002
|
[2] |
NIPPLE-GREASE
|
|
| 9. |
61Q8-21301
|
[2] |
PLATE-COVER
|
|
| 10. |
S109-120256
|
[8] |
BOLT-SOCKET
|
|
